162 Zebra ZXP Series 3 Card Printer Service Manual P1061317-002

5: Replacement Procedures

Procedures

b. Install the Platen Roller Pulley.

c. Install Belt 2 (orange path below).

Step 3. With a TORX T10 driver, tighten the two motor collar screws (7.0.in-lb).
