Ethernet PCBA
Step 2. Using a TORX T10 driver, secure the Ethernet Plate to the Ground Plate with the
four screws.
Reassembly
Replacement is performed by reversing the removal steps:
a. Rear Cover (Page 127).
b. Bottom Cover (Page 126)..
Important • Refer to Appendix I for configuration procedure.
