Zebra ZXP Series 3 Service Manual

H: Upgrade Kit Instructions
Security Lock
P1061317-002 Zebra ZXP Series 3 Card Printer Service Manual 273
Security Lock
Upgrade Kit Instructions
Introduction
These instructions describe installing Security Lock Upgrade Kit P1031925-205 in a Zebra
ZXP Series 3 Card Printer.
In general, only removal directions are presented; unless otherwise noted, replacement would
be performed by reversing the removal steps.
Caution • This kit may only be installed by Zebra trained and certified personnel. Any
attempt to install it by other than Zebra trained and certified personnel will void the
product warranty and may cause damage to the equipment.

Zebra ZXP Series 3 Specifications

General

Color	No
Card size	54 x 86 mm
Card types	Magnetic stripe (ISO 7811), PVC, PVC Composite, Smart card
Card feeder	Yes
Print technology	Dye-sublimation
Maximum resolution	300 DPI
Print speed (color)	180 card/h
Print speed (monochrome)	750 card/h
Printing media thickness	762 µm
Duplex print speed (color)	140 card/h
Display	LCD
Certification	FCC, CE, UL, CUL
Product color	Grey, White
Internal memory	32 MB
Built-in barcodes	EAN13, EAN8, Interleaved 2/5, PDF417, UPC-A
Total input capacity	100 sheets
Display number of characters	16
Compatible operating systems	Windows
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 30 °C
Storage relative humidity (H-H)	20 - 70 %
Operating relative humidity (H-H)	20 - 65 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Interface	USB
Optional connectivity	Ethernet, USB 2.0

Weight and Dimensions

Weight	5530 g
Dimensions (WxDxH)	201 x 368 x 309 mm
