Zebra ZXP Series 3 Service Manual

274 Zebra ZXP Series 3 Card Printer Service Manual P1061317-002
H: Upgrade Kit Instructions
Security Lock
Parts List
Special Tools
• TORX T10 Driver
Procedure
Upgrade Kit: P1031925-205; KIT, UPGRADE, SECURITY
QTY PART NUMBER DESCRIPTION
1 P1028337-001 KIT,SECURITY,ZXP3
1 P1027744 COVER,CATCHER,SECURITY
1 P1026175-004 ASSY,ENCLOSURE,TOP,ZXP3
6 806597G-406 SCR,PH,TORX,PLAST,4-.37L,ZN
1 P1026181-002 BADGE,OCP,ZXP3
3 P1028876 STRIP,FOAM,ADHES,DOUBLE-SIDED
1 210232-030 COVER,FEEDER
Electric Shock Caution • Before performing any of the procedures in this section, set
the printer power to OFF (O) and disconnect the power cord.
Electrostatic Discharge Caution • This replacement procedure must be performed at a
static-free work station, an anti-static wrist strap must be worn and properly terminated,
or other appropriate protection must be used.
Caution • Before beginning any of the steps that follow, read completely through this
procedure. If you do not have the specified tools, or if any step(s) seem beyond your skill
or experience level, do not attempt the procedure. You may cause additional damage to
the printer.

Zebra ZXP Series 3 Specifications

General

Color	No
Card size	54 x 86 mm
Card types	Magnetic stripe (ISO 7811), PVC, PVC Composite, Smart card
Card feeder	Yes
Print technology	Dye-sublimation
Maximum resolution	300 DPI
Print speed (color)	180 card/h
Print speed (monochrome)	750 card/h
Printing media thickness	762 µm
Duplex print speed (color)	140 card/h
Display	LCD
Certification	FCC, CE, UL, CUL
Product color	Grey, White
Internal memory	32 MB
Built-in barcodes	EAN13, EAN8, Interleaved 2/5, PDF417, UPC-A
Total input capacity	100 sheets
Display number of characters	16
Compatible operating systems	Windows
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 30 °C
Storage relative humidity (H-H)	20 - 70 %
Operating relative humidity (H-H)	20 - 65 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Interface	USB
Optional connectivity	Ethernet, USB 2.0

Weight and Dimensions

Weight	5530 g
Dimensions (WxDxH)	201 x 368 x 309 mm
