Program features 141
Diagnostics
80.16 EVACUATION SPEED Defines the speed reference used in the evacuation mode.
80.17 SPEED2 Defines an additional speed reference which can be used instead of the
nominal speed based on the floor distance.
80.18 SPEED3 Defines an additional speed reference which can be used instead of the
nominal speed based on the floor distance.
80.19 OFF DLY SPD LIM Defines the elevator speed limit for activating the extended off-delay time
periods defined with parameters 80.20…80.23.
80.20 SPEED2 OFF DLY Defines the off-delay time for the speed2.
80.21 MED SPD OFF DLY Defines the off-delay time for the medium speed.
80.22 NOM SPD OFF DLY Defines the off-delay time for the nominal speed.
80.23 SPEED3 OFF DLY Defines the off-delay time for the speed3.
Signals Additional information
Actual signals
05.01 LIFT SW bit 5
(SPEED1 ACT)
Displays whether the speed1 is the current speed reference used by the
elevator.
05.01 LIFT SW bit 6
(LEVELING ACT)
Displays whether the leveling speed is the current speed reference used
by the elevator.
05.01 LIFT SW bit 7
(RELEVELING ACT)
Displays whether the releveling speed is the current speed reference
used by the elevator.
05.01 LIFT SW bit 8
(MEDIUM SPD ACT)
Displays whether the medium speed is the current speed reference used
by the elevator.
05.01 LIFT SW bit 9
(NOMINAL SPD ACT)
Displays whether the nominal speed is the current speed reference used
by the elevator.
05.01 LIFT SW bit 10
(INSPECTION SPD ACT)
Displays whether the inspection speed is the current speed reference
used by the elevator.
05.01 LIFT SW bit 12
(EVAC SPD ACT)
Displays whether the evacuation speed is the current speed reference
used by the elevator.
05.01 LIFT SW bit 13
(SPEED2 ACT)
Displays whether the speed2 is the current speed reference used by the
elevator.
05.01 LIFT SW bit 14
(SPEED3 ACT)
Displays whether the speed3 is the current speed reference used by the
elevator.
05.03 LIFT SPEED SEL Displays the elevator speed used based on the Speed reference
selection function.
05.04 LIFT SPEED ACT Displays the actual elevator speed in m/s.
Parameters Additional information
