Analog Duplex System
Subject to Export Control, see Cover Page for details.
8-24
Freq Inc (Analyzer)
Sets the value applied to the RF Analyzer Input Frequency when the [INC Ana Freq] / [DEC Ana
Freq] Soft Key soft keys are pressed. Unit of measure for incremented value are MHz, kHz or Hz
as defined by user.
IF BW
Selects the IF Bandwidth Filter included in the demodulation path. AM USB and LSB are limited
to 4 kHz IF BW. IF BW options for AM and FM are:
Offset
When Manual is selected as the method of setting RF input, this field specifies the difference
between the RF input signal and the manually tuned analyzer frequency.
Demod
Selects the type of demodulation applied to the RF Input Signal.
Resolution
Sets the RF Input Signal’s frequency resolution setting. Setting options are 1 Hz or 10 Hz.
Information Flags
Manual or Autotune
Indicates the Mode selected for setting the RF Frequency. When Autotune is selected the
Offset value can not be defined.
Squelch
When the Incoming signal is suppressed by the Squelch filter, a Squelch flag indicator
appears on the Analyzers Tile. When the tile is minimized, (SQ) is displayed; when the tile is
maximized SQUELCH is displayed.
AM (kHz) FM (kHz)
6.25 6.25
8.33 10
10 12.5
12.5 25
25 30
30 100
300
