Analog Duplex System
Subject to Export Control, see Cover Page for details.
8-42
6. Press TEST Key to return to the Analog Duplex Test Tiles.
7. Select IQ Gen from the Modulation drop-down menu on the Generators Tile
. The Test Set
now displays the selected IQ file.
Fig. 8-36 IQ Gen Selection
