Installation
Subject to Export Control, see Cover Page for details.
2-3
British
The UK lead is fitted with an ASTA approved molded plug conforming to BS 1363.
A replaceable 13 A fuse conforming to BS 1362 is contained within the plug. This fuse is only
designed to protect the lead assembly. Do not use the plug if the fuse cover is damaged or
removed from the fuse holder.
Fig. 2-2 British Class I Power Cord
North American
The North American lead is fitted with a NEMA 5-15P (Canadian CS22.2 No 42) plug and
carries approvals from UL and CSA for use in the USA and Canada.
Fig. 2-3 North American Class I Power Cord
EARTH
NEUTRAL
UK
Country IEX 320 Plug Type Aeroflex PN
United Kingdom Straight through 23422/001
United Kingdom Right angled 23422/002
NEUTRAL
EARTH
N. AMERICA
Country IEX 320 Plug Type Aeroflex PN
North America Straight through 23422/004
North America Right angled 23422/005
