Detectors

6850

Released: April 2004 6850 Series Gas Chromatograph Service Procedures 164

6. Disconnect the µECD vent tube at the rubber

sleeve.

7. Remove the Torx screw holding the gang fit-

ting onto the detector module, and remove

the gang fitting.

8. Remove the one Torx T-20 screw securing

the top µECD detector cover to the detector

pallet and remove the cover.
