Released: April 2004 6850 Series Gas Chromatograph Service Procedures 251

3. Disconnect the transformer cable (P9).

4. Disconnect the two oven heater spade lugs

(P3 and P4). See Figure 1-2, “AC board con-

nectors” for more information.

5. Remove the flap/AC cable (P10).

6. Loosen the farthest nut on the AC board

bracket.
