Inlets and valves
6850
6850
Released: April 2004 6850 Series Gas Chromatograph Service Procedures 64
7. Remove the insert weldment using the inlet
wrench.
8. Remove the inlet liner and 1/4-inch O-ring.
9. Remove the split vent line from the inlet.
10. Loosen the three T-20 Torx screws that
secure the inlet to the lid.
Insert
weldment
Liner and O-ring
Split vent line
To Next Page
