Digital Inputs
Input Connector
The V16Pro has 16 opto-isolated inputs that can control the show operation. If desired, the software may
be configured to allow the front panel buttons to mimic these inputs. Otherwise, the front panel buttons
operate independently, as an additional set of sixteen inputs. We’ll describe your configuration operation in
a couple of pages.
Pin
Connection
Pin
Connection
1
Input 1
20
Input 1 Return
2
Input 2
21
Input 2 Return
3
Input 3
22
Input 3 Return
4
Input 4
23
Input 4 Return
5
Input 5
24
Input 5 Return
6
Input 6
25
Input 6 Return
7
Input 7
26
Input 7 Return
8
Input 8
27
Input 8 Return
9
Input 9
28
Input 9 Return
10
Input 10
29
Input 10 Return
11
Input 11
30
Input 11 Return
12
Input 12
31
Input 12 Return
13
Input 13
32
Input 13 Return
14
Input 14
33
Input 14 Return
15
Input 15
34
Input 15 Return
16
Input 16
35
Input 16 Return
17
N/C
36
N/C
18
N/C
37
N/C
19
N/C
Table 7 – Parallel Input connections.
