Immunity Compliance:
EN 55103-2:2009, Electromagnetic compatibility (Imuunity). Product family standard for
audio, video, audio-visual and entertainment lighting control apparatus for professional
use.
EN 61000-4-2, Electrostatic Discharge, Immunity Compliance
EN 61000-4-3, Radiated Electromagnetic Fields, Immunity Compliance - 80 MHz to 2.7
GHz
EN 61000-4-4, Electrical Fast Transient / Burst, Immunity Compliance
EN 61000-4-5, Surge, Immunity Compliance
EN 61000-4-6, Conducted Immunity Compliance
EN 61000-4-8, Magnetic Field Immunity Compliance - Annex A: 50 Hz to 10 kHz
EN 61000-4-11, Voltage Dips and Variations - Audio Frequency: Annex B
LTC Ports
The LTC ports provide SMPTE/EBU timecode IN for reading and timecode OUT while
generating.
Male XLR (OUT)
Pin
1
GND
2
+
3
-
Female XLR (IN)
Pin
1
GND
2
+
3
-
Serial Ports
The V16Pro provides many serial ports used for programming and controlling show
related machines. The serial interfaces are RS-232, RS422/485, MIDI, USB and Ethernet
giving the V16Pro greater control flexibility for all system and show control functions.
RS-232/422/485 Ports
A few words on the RS-232C port differences. As shown in the table below, take note of
the differences between the programmer port and the show control ports 1-16.
Programmer cables cannot be used as show control cables and visa versa even if they are
RS-232 only.
1. The programmer port is RS-232C only while the show control ports 1-16 have RS-
232C as well as RS422/485.
