A good level for this is usually 3-5 frames. If the timecode skips ahead (or behind) a number that is less
than the tolerance, the sequence will continue to execute all events normally. If the timecode skips ahead
(or behind) a number of frames that is more than the tolerance, a “dropout” will be registered and the
sequence will either jump ahead (jam-sync mode) or reset (reset mode). For more information on
configuring an individual sequence’s clock, see Sequence Clock on page 14.
Generate Settings
• Preroll Time: Occurs once, on initial start, before reaching the “Start Time.” Any further loop
will go back to the Start Time.
• Start Time: The initial running time
• End Time: The time that the timecode stops or loops
• Loop at End Time: Returns to Start Time when End Time is reached
• SMPTE Muted When Paused or Stopped: No SMPTE time signal is generated on LTC output
when Paused or Stopped.
• SMPTE Level: The output level of the SMPTE/EBU signal in dbVp-p
