Programmer Ports
The V16Pro has three ports that can be used to programming. RS-232 Programmer port, USB or
Ethernet port may be used for programming, control and monitoring.
RS-232C
The V16Pro can be connected to a PC using a cable that is wired as one-to-one. This means pin 2
is wired to pin 2, 3 to 3 and 5 to 5 thru the cable. The connector type is a 9-pin D-sub with female
pins at both ends of the cable. The V16Pro port pin out is listed below:
Pin
Connection
2
RS-232 TXD
3
RS-232 RXD
5
GND
8
+9V Pull Up
Table 2 – Programmer port connections.
USB
The USB Port is used for programming and Live Mode only. The driver can be installed with
WinScriptLive setup file.
Ethernet Ports A and B
The optimal way to program the V16Pro is to use the Ethernet ports. There are two Ethernet ports
labeled A and B. Ethernet port A or B may be used for V16Pro programming control and status
monitoring.
