Alcorn Mcbride V16Pro - LED Indicators

VCore Page 130
LED Indicators
Script/Comm - usually solid green, frequently solid yellow
LED
Connection
Off
No script is loaded, Script failed to load
Solid Green
Script is loaded and running
Fast Blinking Red
SD card for script removed or not detected
Red Single Blink
or Solid Red
Invalid Communication from device
or no response from device
Yellow Single Blink
or Solid Yellow
Valid communication to external devices
Network/Config - usually off, frequently green
LED
Connection
Solid Green
Valid IP address is in place
Slow Blinking Green
Live Mode connected
Solid Yellow
IP Address is 0.0.0.0 and requesting IP
using Alcorn's BOOTP Method
Solid Red
IP Address is 0.0.0.0 and using standard DHCP
(unable to reach DHCP server)
LEDs on Boot
Memory Init:
Script/Comm : yellow in process, red is error 4 seconds
IP/Config: yellow in process, red is error 4 seconds
RTC Init:
Script/Comm: off
IP/Config: red is error 4 seconds
CF Card Init:
Script/Comm: green in process, red is error 4 seconds
IP/Config: off
Network Init:
Script/Comm : off
IP/Config: green in process, red is error 4 seconds
