Parameter Descriptions Chapter 2
P277 DC Link Voltage Sag Scaling At Rated
Load
0 100555555555555AOn/Off Y
P278 Derating Control Enable Threshold 50.00 199.99 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 On/Off Y Y
P279 Derating Control Output Filter Time 9.95 1999.94 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 On/Off Y
P280 Low Voltage Ride Through Recovery
Voltage Boost Coefficient
0 100000000000000%On/Off Y
P281 Low Voltage Ride Through Min Time
Interval
0 1000101010101010101010101010sOn/OffYY
P282 Low Voltage Ride Through Min
Frequency Limit
5 100555555555555 OfflineYY
P283Low Voltage Ride Through Enable0 1111111111111 On/OffYY
P284 Low Voltage Ride Through Min Time
Limit
10 16383 40 40 40 40 40 40 40 40 40 40 40 40 ms Offline Y
P285 Low Voltage Ride Through Max Time
Limit
10 16383 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 ms Offline Y
P286 Low Voltage Ride Through Recovery
Frequency Compensation Factor
-200.00 199.99 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 Offline Y
P287 Low Voltage Ride Through Recovery
Time
10 16383 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500 ms Offline Y
P288 Low Voltage Ride Through System Delay
Correction Factor
-10000.00 10000.00 999.76 999.76 999.76 999.76 999.76 999.76 999.76 999.76 999.76 999.76 999.76 999.76 μs Offline Y
P289 Low Voltage Ride Through Motor Speed
Estimation Filter Time
0.98 1000.00 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 ms Offline Y
P290Voltage Loop Enable 0 1111111111111 Offline Y
P291 SVC Low Frequency Acceleration Time
Enable Frequency Range Upper Limit
0 100 10 10 10 10 10 10 10 10 10 10 10 10 % On/Off Y
P292SVC Low Frequency Acceleration Time1 3276.7555555555555sOn/Off Y
P293 SVC Flux Voltage Boost Coefficient 0 500 300 300 300 300 300 300 300 300 300 300 300 300 % On/Off Y
P294SVC Flux Voltage Boost Upper Frequency0 100101010101010101010101010%On/Off Y
P295 Iq Filter Time For Slip Estimation 0 1000 100 100 100 100 100 100 100 100 100 100 100 100 On/Off Y
P296Current Feedback Filter Time 0 1000101010101010101010101010msOn/Off Y
P297Voltage Feedback Filter Time 0 1000101010101010101010101010msOn/Off Y
P298 Filter Time A For DC Bus Average Value 0 1000 100 100 100 100 100 100 100 100 100 100 100 100 ms On/Off Y
P299Filter Time B For DC Bus Average Value0 1000555555555555msOn/Off Y
P300Digital Output #0 Memory Address0 500999999999999999999999999 On/Off Y
P301Digital Output #0 Logic 0 1000000000000 On/Off Y
No. Name Min. Max. Default Values Units Modify
