Page #157 background image
Rockwell Automation Publication 6000-TD004D-EN-P - November 2017 157
Parameter Descriptions Chapter 2
Analog Input Parameters
Digital Output Parameters
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
P151 Line Voltage Uab Scaling Factor 0.00 199.99 153.00 146.70 175.90 159.90 175.80 169.00 146.50 167.40 159.80 152.80 158.10 143.70 % On/Off Y Y
P152 Line Voltage Ubc Scaling Factor 0.00 199.99 153.00 146.70 175.90 159.90 175.80 169.00 146.50 167.40 159.80 152.80 158.10 143.70 % On/Off Y Y
P153 Line Voltage Ung Scaling Factor 0.00 199.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 % On/Off Y Y
P171 Line Current Phase A Scaling Factor 0.00 199.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 % On/OffY
P172 Line Current Phase B Scaling Factor 0.00 199.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 % On/OffY
P173 Line Current Phase C Scaling Factor 0.00 199.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 % On/OffY
P200 Ia Motor Current Memory Address 0 500 13 13 13 13 13 13 13 13 13 13 13 13 On/Off Y
P201 Motor Ia Scaling Factor 0.00 199.99 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 On/Off Y
P202 Ic Motor Current Memory Address 0 500 14 14 14 14 14 14 14 14 14 14 14 14 On/Off Y
P203 Motor Ic Scaling Factor 0.00 199.99 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 On/Off Y
P204 Motor Uab Voltage Address 0 500 11 11 11 11 11 11 11 11 11 11 11 11 On/Off Y
P205 Motor Uab Voltage Scaling Factor 0.00 199.99 153.00 146.70 175.90 159.90 175.80 169.00 146.50 167.40 159.80 152.80 158.10 143.70 On/Off Y Y
P206 Motor Uac Voltage Scaling Factor 0.00 199.99 153.00 146.70 175.90 159.90 175.80 169.00 146.50 167.40 159.80 152.80 158.10 143.70 On/Off Y Y
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
P300 Digital Output #0 Memory Address 0 500 99 99 99 99 99 99 99 99 99 99 99 99 On/Off Y
P301Digital Output #0 Logic 0 1000000000000 On/Off Y
P302Digital Output #0 Bit Selection 0 15000000000000 On/Off Y
P303Digital Output #0 Delay 0 32767000000000000msOn/Off Y
P304 Digital Output #1 Memory Address 0 500 99 99 99 99 99 99 99 99 99 99 99 99 On/Off Y
P305Digital Output #1 Logic 0 1000000000000 On/Off Y
P306Digital Output #1 Bit Selection 0 15111111111111 On/Off Y
P307Digital Output #1 Delay 0 32767000000000000msOn/Off Y
P308 Digital Output #2 Memory Address 0 500 99 99 99 99 99 99 99 99 99 99 99 99 On/Off Y
P309Digital Output #2 Logic 0 1000000000000 On/Off Y
P310Digital Output #2 Bit Selection 0 15222222220222 On/Off Y
