Chapter 2 Parameter Descriptions
Bypass Mode Switch Parameters
Fault Automatic Switch to Bypass Parameters
Current Limit Parameters
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
P484Bypass Mode Selection 0 4000000000000 OfflineYY
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
P471Fault-To-Bypass 0 1000000000000 OfflineYY
P472Fault-To-Bypass Delay 0 5333333333333 On/OffYY
P473 Fault-To-Bypass Delay When Starting
The Motor
0 60606060606060606060606060s On/OffYY
P474Fault-To-Bypass Minimum Frequency0 75555555555555HzOfflineYY
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
P133 Current Limit Loop Kp 0.0 128.0 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 On/Off Y
P134 Current Limit Loop Ki 0.0 128.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 On/Off Y
P135Current Limit Loop Kd 0 12800000000000000*0.001On/Off Y
P436Current Limitation Enable 0 1111111111111 On/OffYY
P438 Current Limitation Enable Frequency
Range Lower Limit
0 100000000000000 On/OffYY
P441 Current Limitation Threshold 0.00 399.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 On/Off Y Y
P442 Current Limitation Heating Time 0 16384 60 60 60 60 60 60 60 60 60 60 60 60 s On/Off Y Y
P443 Current Limitation Cooling Time 0 16384 540 540 540 540 540 540 540 540 540 540 540 540 s On/Off Y Y
P444 Current Limitation Decel Ramp Slope
Change
0.00 399.99 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 On/Off Y Y
P445 Current Limitation Cycle Load Control
Enable
0 1000000000000 On/OffYY
