Chapter 2 Parameter Descriptions
Pre-charge Control Parameters Customized Trip Parameters
P102Fan Control Fan Stop Delay 0 10111111111111mOn/OffYY P106 Fan Control Transformer Cabinet Fan
Quantity Upper Limit
0 16101010101010101010101010 On/OffYY
P116 Fan Control TX Cabinet Fan Fault Trip
Delay
1 60303030303030303030303030mOn/OffYY
P117 Fan Control Filter Cabinet Fan Fault Trip
Delay
1 60303030303030303030303030mOn/OffYY
P186 Drive Start Delay 0 32767 10000 10000 10000 10000 10000 10000 10000 10000 10000 10000 10000 10000 ms On/Off Y No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
P103Pre-charge Enable 0 1000000000000 On/OffYY P104 Pre-charge Feedback Delay 0 100 20 20 20 20 20 20 20 20 20 20 20 20 100 ms On/Off Y P105 Pre-charge DC Bus Threshold 0 100 80 80 80 80 80 80 80 80 80 80 80 80 % On/Off Y P118Pre-charge Max Time 2 20666666666666sOn/OffYY P119Pre-charge Min Repeat Interval5 60555555555555mOn/OffYY P120 Pre-charge Primary Voltage Threshold 0 100 80 80 80 80 80 80 80 80 80 80 80 80 % On/Off Y P180 Pre-charge Resistor Short Circuit Fault
Threshold
0 10222222222222%On/Off Y
P181 Pre-charge Resistor Short Circuit Fault
Delay
0 10000 500 500 500 500 500 500 500 500 500 500 500 500 ms On/Off Y
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
P030 Powercell Fault Trip Signal Mask -32768 32767 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 Offline Y Y P031 System Fault Trip Signal Mask -32768 32767 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 Offline Y Y P145 System Fault B Trip Signal Mask -32768 32767 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 Offline Y Y
