Page #170 background image
170 Rockwell Automation Publication 6000-TD004D-EN-P - November 2017
Chapter 2 Parameter Descriptions
Protection Parameters
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
P079 VFD Minimum Overload Current 0.00 399.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 % On/Off Y Y
P080 VFD Overload Current 0.00 399.99 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 % On/Off Y Y
P081 VFD Overload Time 0 32767 60 60 60 60 60 60 60 60 60 60 60 60 s On/Off Y Y
P082 VFD Overload Cycle Time 0 32767 600 600 600 600 600 600 600 600 600 600 600 600 s On/Off Y Y
P107 VFD Overload Current Offset 0.00 399.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 % On/Off Y
P108 Motor Overload Current Offset 0.00 399.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 % On/Off Y
P110 Heating Current Threshold 0.00 399.99 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 % On/Off Y
P154 Line Over Voltage Fault Threshold 0.00 199.99 115.00 115.00 115.00 115.00 115.00 115.00 115.00 115.00 115.00 115.00 115.00 115.00 % On/Off Y Y
P155 Line Over Voltage Fault Delay 0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y Y
P156 Line Under Voltage Warning Threshold 0 100 80 80 80 80 80 80 80 80 80 80 80 80 % On/Off Y Y
P157 Line Under Voltage Warning Delay 0 32767 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 ms On/Off Y Y
P158 Line Neutral Over Voltage Warning
Threshold
0.00 199.99 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 % On/Off Y Y
P159 Line Neutral Over Voltage Warning Delay 0 32767 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 ms On/Off Y Y
P160 Line Neutral Over Voltage Fault
Threshold
0.00 199.99 80.00 80.00 80.00 80.00 80.00 80.00 80.00 80.00 80.00 80.00 80.00 80.00 % On/Off Y Y
P161 Line Neutral Over Voltage Fault Delay 0 32767 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 ms On/Off Y Y
P162 Line Voltage Positive Sequence Filter
Time
0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y Y
P163 Line Voltage Negative Sequence Filter
Time
0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y Y
P164 Line Voltage Negative Sequence Fault
Threshold
0.00 199.99 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 % On/Off Y Y
P165 Line Voltage Negative Sequence Fault
Delay
0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y Y
P166 Line Voltage Phaser Sequence Reverse
Enable
0 1000000000000 On/OffYY
P168 Line Current Filter Time 0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y Y
P169 Line Short Circuit Fault Threshold 0 400 180 180 180 180 180 180 180 180 180 180 180 180 % On/Off Y Y
P170 Line Short Circuit Fault Delay 0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y Y
P174 Line Current Positive Sequence Filter
Time
0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y Y
P175 Line Current Negative Sequence Filter
Time
0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y Y
