Allen-Bradley PowerFlex 6000 Firmware, Parameters, And Troubleshooting Manual

Rockwell Automation Publication 6000-TD004D-EN-P - November 2017 171
Parameter Descriptions Chapter 2
P176 Line Current Negative Sequence Fault
Threshold
0.00 199.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 % On/Off Y Y
P177 Line Current Negative Sequence Fault
Delay
0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y Y
P208 Phase Over Current Enable Frequency
Range Upper limit
0 100 10 10 10 10 10 10 10 10 10 10 10 10 On/Off Y
P209Phase Over Current Filter Time 0 32767555555555555 On/Off Y P210 Phase Over Current Threshold 0.00 399.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 On/Off Y Y P211 Filter Time For Abnormal Output Voltage 0 32767 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 ms On/Off Y P212 Filter Time For Output Short-Circuit 0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y Y P213 Output Short-Circuit Fault Threshold 0.00 399.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 On/OffYY P214 Motor Minimum Overload Current 0.00 399.99 104.99 104.99 104.99 104.99 104.99 104.99 104.99 104.99 104.99 104.99 104.99 104.99 % On/Off Y Y P215 Motor Overload Cycle Time 0 32767 600 600 600 600 600 600 600 600 600 600 600 600 s On/Off Y Y P216 MotorOverload Trip Threshold 0.00 399.99 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 % On/Off Y Y P217 Motor Overload Time 0 32767 60 60 60 60 60 60 60 60 60 60 60 60 s On/Off Y Y P221 Filter Time For Output Over Voltage 0 32767 100 100 100 100 100 100 100 100 100 100 100 100 ms On/Off Y P222 Output Over Voltage Fault Threshold 0.00 199.99 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 On/Off Y Y
P223 Output Voltage Deviation Warning
Threshold
0.00 199.99 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 On/Off Y Y
P224 Output Voltage Deviation Fault
Threshold
0.00 199.99 80.00 80.00 80.00 80.00 80.00 80.00 80.00 80.00 80.00 80.00 80.00 80.00 On/Off Y Y
P226 Output Voltage Abnormality Warning
Cancellation Threshold
0.00 199.99 50.00 50.00 50.00 50.00 50.00 50.00 50.00 50.00 50.00 50.00 50.00 50.00 On/Off Y
P227 Ground Fault Detection Scaling
Correction Factor
0.00 199.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 On/Off Y
P228 Filter Time For Ground Fault 0 32767 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 ms On/Off Y P229 Ground Fault Warning Threshold 0.00 199.99 8.00 8.00 8.00 8.00 8.00 8.00 8.00 8.00 8.00 8.00 8.00 8.00 On/Off Y P230 Ground Fault Trip Threshold 0.00 199.99 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 On/Off Y P231 Filter Time For Overspeed Fault (Upper
Limit)
0 32767 100 100 100 100 100 100 100 100 100 100 100 100 On/Off Y
P232 Filter Time For Overspeed Fault (Lower
Limit)
0 32767 100 100 100 100 100 100 100 100 100 100 100 100 On/Off Y
P233 Threshold Of Over-Speed Fault At Lower
Frequency Limit
0.00 199.99 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 On/Off Y
P234 Threshold Of Over-Speed Fault At Upper
Frequency Limit
0.00 199.99 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 On/Off Y
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
