Functional Descriptions Chapter 1
For each power cell, there are 21 parameters that can be read or written, as shown
in the following table.
Table 6 - List of Power Cell Parameters
Customized Trip
This function is used to set the trip signal behavior to suit an application. The
user can define the fault protection level based on their application by
configuring the trip signal combination. For example, if a trip occurs, the drive
displays the signal and stops, or the drive masks the trip signal and simply stops.
The following parameters are used for this function:
• Powercell Fault Trip Signal Mask Register (P030)
• System Fault Trip Signal Mask Register (P031)
• Logic Fault A Trip Signal Mask Register (P032)
• Logic Fault B Trip Signal Mask Registaer (P033)
Set the bit to “1” to allow trip and not mask, or “0” to avoid trip and mask trip
signal.
Parameter Number Desripciotn Read/Write
1 DC Under Voltage Fault Threshold R/W
2 DC Under/Over Voltage Warning Hysteresis R/W
3 DC Over Voltage1 Trip Threshold R/W
4 DC Over Voltage1 Trip Delay Time R/W
5 DC Over Voltage2 Trip Threshold R/W
6 DC Over Voltage2 Trip Delay Time R/W
7 Transformer Secondary Rated Voltage R/W
8 Transformer Secondary Rated Frequency R/W
9 Input Phase Loss Signal Filter R/W
10 Single Phase Loss Pulse Counts R/W
11 Pulse Width For Single Phase Loss To Two Phase Loss Transition R/W
12 Single Phase Loss Recovery Delay R/W
13 Single Phase Loss Detection Dela R/W
14 Minimum Pulse Width For Two Phase Loss R/W
15 Power Cell PN R
16 Power Cell PN2 R
17 Firmware Rev # R
18 PCCB Hardware Rev # R
19 Power Cell Rated Current R
20 Power Cell Rated Voltage R
21 Power Cell Feature Select 1 R
