Rockwell Automation Publication 6000-TD004D-EN-P - November 2017 7
Preface
About this Publication
This manual provides details regarding functions, parameters and
troubleshooting information for medium voltage PowerFlex® 6000 drives.
Who Should Use This Manual
This manual is intended for qualified service personnel responsible for
troubleshooting and repairing medium voltage PowerFlex 6000 drives. You
should have previous experience with, and basic understanding of, electrical
terminology, procedures, required troubleshooting equipment, equipment
protection procedures and methods, and safety precautions.
Additional Resources
These documents contain additional information concerning related products
from Rockwell Automation.
You can view or download publications at
http:/www.rockwellautomation.com/literature/
. To order paper copies of
technical documentation, contact your local Allen-Bradley distributor or
Rockwell Automation sales representative.
Acronyms and Abbreviations
Resource Description
PowerFlex 6000 Medium Voltage Variable
Frequency Drive Installation Manual,
publication 6000-IN006
Provides instructions for installing the drive, dimensions,
requirements, and wiring information.
PowerFlex 6000 Medium Voltage Variable
Frequency Drive Shipping and Handling
Manual, publication 6000-IN008
Provides instructions for shipping and handling a Medium Voltage
variable frequency drive and related equipment.
PowerFlex 6000 Medium Voltage Variable
Frequency Drive User Manual, publication
6000-UM002
Provides instructions for daily recurring drive usage, HMI interface and
maintenance tasks for the product’s end-user.
Acronym/
Abbreviation
Description Acronym/
Abbreviation
Description
A2D Analog to Digital FPGA Field-Programmable Gate Array
A/D Analog/Digital Freq Frequency
AC Alternating Current GND Ground
ACB Analog Control Board Gnrl General
Accel Acceleration HECS Hall Effect Current Sensor
ADC Analog to Digital Converter Hi High
Anlg Analog HP Horse Power
BW Bandwidth HW Hardware
Cap Capacitor I Current
Ch Channel IGDPS Isolated Gate Driver Power Supply
Chn Channel Init Initialize
