Chapter 2 Parameter Descriptions
Analog Output Parameters
P311Digital Output #2 Delay 0 32767000000000000msOn/Off Y
P312 Digital Output #3 Memory Address 0 500 99 99 99 99 99 99 99 99 99 99 99 99 On/Off Y
P313Digital Output #3 Logic 0 1000000000000 On/Off Y
P314Digital Output #3 Bit Selection 0 15333333333333 On/Off Y
P315Digital Output #3 Delay 0 32767000000000000msOn/Off Y
P316 Digital Output #4 Memory Address 0 500 99 99 99 99 99 99 99 99 99 99 99 99 On/Off Y
P317Digital Output #4 Logic 0 1000000000000 On/Off Y
P318Digital Output #4 Bit Selection 0 15444444444444 On/Off Y
P319Digital Output #4 Delay 0 32767000000000000msOn/Off Y
P320 Digital Output #5 Memory Address 0 500 99 99 99 99 99 99 99 99 99 99 99 99 On/Off Y
P321Digital Output #5 Logic 0 1000000000000 On/Off Y
P322Digital Output #5 Bit Selection 0 15555555555555 On/Off Y
P323Digital Output #5 Delay 0 32767000000000000msOn/Off Y
P324 Digital Output #6 Memory Address 0 500 99 99 99 99 99 99 99 99 99 99 99 99 On/Off Y
P325Digital Output #6 Logic 0 1000000000000 On/Off Y
P326Digital Output #6 Bit Selection 0 15666666666666 On/Off Y
P327Digital Output #6 Delay 0 32767000000000000msOn/Off Y
P328 Digital Output #7 Memory Address 0 500 99 99 99 99 99 99 99 99 99 99 99 99 On/Off Y
P329Digital Output #7 Logic 0 1000000000000 On/Off Y
P330Digital Output #7 Bit Selection 0 15777777777777 On/Off Y
P331Digital Output #7 Delay 0 32767000000000000msOn/Off Y
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
P332 Analog Output #1 Memory Address 0 500 252 252 252 252 252 252 252 252 252 252 252 252 On/Off Y
P333 Analog Output #1 Filter Time 0 32767 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 ms On/Off Y
P334Analog Output #1 Offset -1001000000000000000 On/Off Y
P335 Analog Output #1 Scaling Factor 0.00 199.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 On/Off Y Y
P336 Analog Output #2 Memory Address 0 500 206 206 206 206 206 206 206 206 206 206 206 206 On/Off Y
