Rockwell Automation Publication 6000-TD004D-EN-P - November 2017 161
Parameter Descriptions Chapter 2
Over Speed Parameters
Voltage Sag Parameters
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
P460 Rated Output Frequency 0 75 50 50 50 50 50 50 50 50 50 50 50 50 Offline Y Y
P466 Maximum Output Frequency 0 75 50 50 50 50 50 50 50 50 50 50 50 50 Offline Y Y
P467Over Speed Enable 0 1000000000000 OfflineYY
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
P182Derating Function Enable 0 1111111111111 On/Off
P183 Voltage Lower Threshold For Drive
Derating Per Cooling Fan Input Voltage
Drop
0 100 70 70 70 70 70 70 70 70 70 70 70 70 On/Off
P184 Voltage Upper Threshold For Drive
Derating Per Cooling Fan Input Voltage
Drop
0 100 75 75 75 75 75 75 75 75 75 75 75 75 On/Off
P185 Drive Output Current Upper Limitation
Per Cooling Fan Input Voltage Drop
0 100 76 76 76 76 76 76 76 76 76 76 76 76 On/Off
P268 Flux Control Signal Filter Time 0.00 13663.80 10000.08 10000.08 10000.08 10000.08 10000.08 10000.08 10000.08 10000.08 10000.08 10000.08 10000.08 10000.08 ms On/Off Y
P269 System Derating Control Signal Filter
Time
9.60 13663.80 10000.08 10000.08 10000.08 10000.08 10000.08 10000.08 10000.08 10000.08 10000.08 10000.08 10000.08 10000.08 ms On/Off Y
P272 Flux Control Compensation Gain 0 100 25 25 25 25 25 25 25 25 25 25 25 25 % On/Off Y
P273Flux Control Regulation Control Enable0 1111111111111 On/Off Y
P276Flux Control-Lag Band Width 0 100333333333313 On/Off Y
P278 Derating Control Enable Threshold 50.00 199.99 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 On/Off Y Y
P279 Derating Control Output Filter Time 9.95 1999.94 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 9.95 On/Off Y
