156 Rockwell Automation Publication 6000-TD004D-EN-P - November 2017
Chapter 2 Parameter Descriptions
VF Curve Setting Parameters
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
P111Slip Compensation Enable 0 1000000000000 On/Off Y
P271 Flux Delay 0 5000 500 500 500 500 500 500 500 500 500 500 500 500 ms On/Off Y
P291 SVC Low Frequency Acceleration Time
Enable Frequency Range Upper Limit
0 100 10 10 10 10 10 10 10 10 10 10 10 10 % On/Off Y
P292SVC Low Frequency Acceleration Time1 3276.7555555555555sOn/Off Y
P293 SVC Flux Voltage Boost Coefficient 0 500 300 300 300 300 300 300 300 300 300 300 300 300 % On/Off Y
P294 SVC Flux Voltage Boost Upper Frequency 0 100 10 10 10 10 10 10 10 10 10 10 10 10 % On/Off Y
P295 Iq Filter Time For Slip Estimation 0 1000 100 100 100 100 100 100 100 100 100 100 100 100 On/Off Y
P375 Frequency At First Point for 5 Point VF 0.00 10.00 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 % Offline Y Y
P376 Amplitude At First Point for 5 Point VF 0.00 3.00 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 % Offline Y Y
P377 Frequency At Second Point for 5 Point VF 10 100 20 20 20 20 20 20 20 20 20 20 20 20 % Offline Y Y Y
P378 Amplitude At Second Point for 5 Point VF 0 100 10 10 10 10 10 10 10 10 10 10 10 10 % Offline Y Y Y
P379 Frequency At Third Point for 5 Point VF 10 100 40 40 40 40 40 40 40 40 40 40 40 40 % Offline Y Y
P380 Amplitude At Third Point for 5 Point VF 0 100 27 27 27 27 27 27 27 27 27 27 27 27 % Offline Y Y
P381 Frequency At Fourth Point for 5 Point VF 10 100 60 60 60 60 60 60 60 60 60 60 60 60 % Offline Y Y
P382 Amplitude At Fourth Point for 5 Point VF 0 100 45 45 45 45 45 45 45 45 45 45 45 45 % Offline Y Y
P383 Frequency At Fifth Point for 5 Point VF 10 100 80 80 80 80 80 80 80 80 80 80 80 80 % Offline Y
P384 Amplitude At Fifth Point for 5 Point VF 0 100 70 70 70 70 70 70 70 70 70 70 70 70 % Offline Y Y
P451Low Speed Voltage Compensation0 3111111111111%OfflineYY
P452 Low Speed Voltage Compensation
Frequency Threshold
0 100 20 20 20 20 20 20 20 20 20 20 20 20 On/Off Y Y
P453V/F Curve 0 5555555555555 OfflineYY
P454Flux Time 0 102222222222 2sOffline Y
P455 Modulation Index 0.0 110.0 84.0 87.6 77.3 85.0 83.8 87.0 87.0 81.0 85.0 83.7 91.0 89.0 On/Off Y Y
P456 Motor Voltage Upper Limit 0.00 110.0 84.0 87.6 77.3 85.0 83.8 87.0 87.0 81.0 85.0 83.7 91.0 89.0 On/Off Y Y
P458 Coefficient A 0 100 40 40 40 40 40 40 40 40 40 40 40 40 Offline Y
