94 Rockwell Automation Publication 6000-TD004D-EN-P - November 2017
Chapter 2 Parameter Descriptions
System Fault Trip Signal Mask
Linear Number: P031
Default Value: -1
Minimum Value: -32768
Maximum Value: 32767
Access Level: Setup, R&D
Read/Write: Read/Write
Modify Level: Offline only
This parameter sets the System Fault Trip Signal Mask register.
System Fault B Trip Signal Mask
Linear Number: P145
Default Value: -1
Minimum Value: -32768
Maximum Value: 32767
Access Level: Setup, R&D
Read/Write: Read/Write
Modify Level: Offline only
This parameter sets the System Fault Trip B Signal Mask register.
Over Speed Parameters
Rated Output Frequency
Linear Number: P460
Default Value: 50
Minimum Value: 0
Maximum Value: 75
pAccess Level: Setup, R&D
Read/Write: Read/Write
Modify Level: Offline only
This parameter sets the Rated Output Frequency.
Bit Description Detail
2 Fan Failure in Fan Group #1 0 = Not mask, 1 = Mask
3 Output Over Voltage 0 = Not mask, 1 = Mask
4 Abnormal Output Voltage 0 = Not mask, 1 = Mask
6Over Speed Fault 0 = Not mask, 1 = Mask
7 Motor Stalled 0 = Not mask, 1 = Mask
9 Output phase Over Current 0 = Not mask, 1 = Mask
10 VFD Over Current 1 0 = Not mask, 1 = Mask
Bit Description Detail
6 Fan Failure in Fan Group #4 0 = Not mask, 1 = Mask
9 DC Bus Under Voltage Fault 0 = Not mask, 1 = Mask
