Parameter Descriptions Chapter 2
Pre-charge Resistor Short Circuit Fault Threshold
Linear Number: P180
Default Value: 2%
Minimum Value: 0%
Maximum Value: 10%
Access Level: R&D
Read/Write: Read/Write
Modify Level: Online/Offline
This parameter sets the threshold for pre-charge resistor short circuit fault.
During pre-charging, if the line side voltage does not reach the set threshold
within the duration set in Pre-charge Resistor Short Circuit Fault Delay (P181), it
is considered that the pre-charge resistor has short circuited.
Pre-charge Resistor Short Circuit Fault Delay
Linear Number: P181
Default Value: 500 ms
Minimum Value: 0 ms
Maximum Value: 10000 ms
Access Level: R&D
Read/Write: Read/Write
Modify Level: Online/Offline
This parameter sets the delay for pre-charge resistor short circuit fault. During
pre-charging, if the line side voltage does not reach the threshold set in Pre-charge
Resistor Short Circuit Fault Threshold (P180) within this time, it is considered
that the pre-charge resistor has short circuited.
Customized Trip Parameters
Powercell Fault Trip Signal Mask
Linear Number: P030
Default Value: -1
Minimum Value: -32768
Maximum Value: 32767
Access Level: Setup, R&D
Read/Write: Read/Write
Modify Level: Offline only
This parameter sets the Powercell Fault Trip Signal Mask register.
Bit Description Detail
4Communicator Error 0 = Not mask, 1 = Mask
5 No PWM Pulse For IGBT 0 = Not mask, 1 = Mask
6 Bypass Hardware Fault 0 = Not mask, 1 = Mask
7 Communication Link Fault 0 = Not mask, 1 = Mask
8 PCCB Version Not Compatible 0 = Not mask, 1 = Mask
10 Over Temperature 0 = Not mask, 1 = Mask
12 One Phase Lost 0 = Not mask, 1 = Mask
13 Two Phases Lost 0 = Not mask, 1 = Mask
