Allen-Bradley PowerFlex 6000 Firmware, Parameters, And Troubleshooting Manual

154 Rockwell Automation Publication 6000-TD004D-EN-P - November 2017
Chapter 2 Parameter Descriptions
Ramp Parameters Frequency Setting Parameters
P359 Actual Frequency HMI Display Decimal
Part
0 1000000000000000 On/Off Y
P360 Motor Current HMI Display Filter Time 0 32767 2000 2000 2000 2000 2000 2000 2000 2000 2000 2000 2000 2000 ms On/Off Y P361Motor Current HMI Display Integer Part0 5000000000000000 On/OffYYY P362Motor Current HMI Display Decimal Part0 1000000000000000 On/Off Y P371 Rated Frequency HMI Display Address 0 500 221 221 221 221 221 221 221 221 221 221 221 221 On/Off Y P372 Motor Voltage HMI Display Address 0 500 119 119 119 119 119 119 119 119 119 119 119 119 On/Off Y P373 Actual Frequency HMI Display Address 0 500 252 252 252 252 252 252 252 252 252 252 252 252 On/Off Y P374 Motor Current HMI Display Address 0 500 118 118 118 118 118 118 118 118 118 118 118 118 On/Off Y P479Power Display Enable 0 1000000000000 On/OffYY No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
P399 Deceleration Time 1.0 3276.7 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 s On/Off Y Y Y P401 Acceleration Time 1.0 3276.7 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 s On/Off Y Y Y P402 Acceleration Ramp Transition Time 0.00 100.00 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.990.990.990.990.99% On/Off Y
P403 Acceleration Time Unit 0.0 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 On/Off Y P405 Deceleration Ramp Transition Time 0.00 100.00 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.990.990.990.990.99% On/Off Y
P406 Deceleration Time Unit 0.0 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 On/Off Y P409 Amplification Coefficient Of Error Terms 0.00 199.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 On/Off Y
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
P413Frequency Command Lower Limit-100100000000000000 On/Off Y P414 Frequency Command Deadband Upper
Limit
0 100 10 10 10 10 10 10 10 10 10 10 10 10 Offline Y
P415 Frequency Command Upper Limit -100 100 100 100 100 100 100 100 100 100 100 100 100 100 On/Off Y
