Preface
CIB Customer Interface Board Inv Inverter
CMC Common Mode Choke IO Input/Output
Cmd Command Isoltn Sw Isolation Switch
Conv Converter L Inductance
CT Current Transformer L Line
Ctctr Contactor LED Light-emitting diode
Cur Current Liq Liquid
DAC Digital to Analog Converter LR Line Reactor
DB Dynamic Braking Lo Low
DC Direct Current LV Low Voltage
DCB Drive Control Board M Machine
DCSL Drive Control and Synchronization Link Magntz Magnetizing
DD Dimensional Drawings Max Maximum
Decel Deceleration Min Minimum
DIM Drive Identity Module Mstr Master
Dly Delay MTR Motor
DO Drive Output NVRAM Non-Volatile Random Access Memory
DPI Drive Peripheral Interface OC Overcurrent
DPM Drive Processor Module OL Overload
DrvIn Drive Input OP Output
ED Electrical Drawings PF Power Factor
ESP Electric Submersible Pump PFC Power Factor Correction
Fbk Feedback PID Proportional, Integral, Derivative (process control)
Flt Fault PLC Programmable Logic Control
Fltr Filter Sync Synchronous
FO Fiber-Optic Tach Tachometer
FOB Fiber-Optic Interface Board
FOI Fiber-Optic Interface TFB Temperature Feedback Board
PWM Pulse-Width Modulation TFB3 Temperature Feedback Board, 3
rd
generation
Rect Rectifier Trp Trip
Rot’n Rotation Trq Torque
SCB Signal Conditioning Board TSN Transient Suppression Network
SCR Silicon-Controlled Rectifier UB Unbalance
SGCT Symmetrical-Gate Commutated Thyristor UPS Uninterrupted Power Supply
Slv Slave USART Universal Synchronous/Asynchronous Transmitter/Receiver
Spd Speed V Volt
SPGD Self-Powered Gate Driver VSB Volt Sensing Board
SW Software Wrn Warning
OT Overtemperature Xfer Transfer
OV Overvoltage XIO External Input/Output
PD Parallel Drive
