172 Rockwell Automation Publication 6000-TD004D-EN-P - November 2017
Chapter 2 Parameter Descriptions
P235 Frequency Deviation Warning
Cancellation Threshold
0.00 199.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 On/Off Y
P236 Frequency Deviation Warning Threshold 0.00 199.99 6.00 6.00 6.00 6.00 6.00 6.00 6.00 6.00 6.00 6.00 6.00 6.00 On/Off Y
P237Frequency Deviation Warning Delay0 327678888888888 8msOn/Off Y
P238 Motor Stall Fault Threshold 0.00 199.99 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 On/Off Y Y
P239 Motor Stall Fault Delay 0 32767 6000 6000 6000 6000 6000 6000 6000 6000 6000 6000 6000 6000 ms On/Off Y
P240 Transformer Over Temperature Fault
Delay
0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y
P241 Transformer Over Temperature Warning
Delay
0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y
P254 DC Bus Under Voltage Fault Threshold 0 100 63 63 63 63 63 63 63 63 63 63 63 63 % On/Off Y
P256 Ground Fault Warning Cancellation
Threshold
0.00 199.99 5.00 5.00 5.00 5.00 5.00 5.00 5.00 5.00 5.00 5.00 5.00 5.00 On/Off Y
P257 Motor Stall Warning Cancellation
Threshold
0.00 199.99 2.98 2.98 2.98 2.98 2.98 2.98 2.98 2.98 2.98 2.98 2.98 2.98 On/Off Y
P258 DC Bus Under Voltage Fault Delay 0 32767 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 ms On/Off Y
P266 DC Bus Voltage Deviation Fault Threshold 0 100 25 25 25 25 25 25 25 25 25 25 25 25 % On/Off Y Y
P267 DC Bus Voltage Deviation Fault Filter
Time
0 1000101010101010101010101010msOn/OffYY
P274 DC Bus Under Voltage Warning Threshold 0 100 80 80 80 80 80 80 80 80 80 80 80 80 % On/Off Y Y
P275 DC Bus Under Voltage Warning
Hysteresis Band
0 100555555555555%On/OffYY
P411 Over Speed Lower Limit Reference 0 100 100 100 100 100 100 100 100 100 100 100 100 100 On/Off Y
P412Over Speed Lower Limit Reference0 100000000000000 On/Off Y
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
