184 Rockwell Automation Publication 6000-TD004D-EN-P - November 2017
Chapter 2 Parameter Descriptions
P373 Actual Frequency HMI Display Address 0 500 252 252 252 252 252 252 252 252 252 252 252 252 On/Off Y
P374 Motor Current HMI Display Address 0 500 118 118 118 118 118 118 118 118 118 118 118 118 On/Off Y
P375 Frequency At First Point for 5 Point VF 0.00 10.00 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.990.990.990.990.99% Offline YY
P376 Amplitude At First Point for 5 Point VF 0.00 3.00 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 % Offline Y Y
P377Frequency At Second Point for 5 Point VF10 100202020202020202020202020%OfflineYYY
P378 Amplitude At Second Point for 5 Point VF 0 100 10 10 10 10 10 10 10 10 10 10 10 10 % Offline Y Y Y
P379Frequency At Third Point for 5 Point VF10 100404040404040404040404040%OfflineYY
P380 Amplitude At Third Point for 5 Point VF 0 100 27 27 27 27 27 27 27 27 27 27 27 27 % Offline Y Y
P381Frequency At Fourth Point for 5 Point VF10 100606060606060606060606060%OfflineYY
P382 Amplitude At Fourth Point for 5 Point VF 0 100 45 45 45 45 45 45 45 45 45 45 45 45 % Offline Y Y
P383Frequency At Fifth Point for 5 Point VF10 100808080808080808080808080%Offline Y
P384 Amplitude At Fifth Point for 5 Point VF 0 100 70 70 70 70 70 70 70 70 70 70 70 70 % Offline Y Y
P385Deceleration Process Enable 0 1000000000000 OfflineYY
P386 Deceleration Time 1 1.0 3276.7 150.0 150.0 150.0 150.0 150.0 150.0 150.0 150.0 150.0 150.0 150.0 150.0 s On/Off Y Y
P387 Deceleration Frequency 1 0 75 30 30 30 30 30 30 30 30 30 30 30 30 On/Off Y Y
P388 Deceleration Time 2 1.0 3276.7 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0 s On/Off Y Y
P389 Deceleration Frequency 2 0 75 20 20 20 20 20 20 20 20 20 20 20 20 On/Off Y Y
P390 Deceleration Time 3 1.0 3276.7 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0 s On/Off Y Y
P391 Deceleration Frequency 3 0 75 10 10 10 10 10 10 10 10 10 10 10 10 On/Off Y Y
P392 Deceleration Time 4 1.0 3276.7 100.0 100.0 100.0 100.0 100.0 100.0 100.0 100.0 100.0 100.0 100.0 100.0 s On/Off Y Y
P393Flying Start Compensation Enable0 1111111111111 On/OffYY
P394 Flying Start Compensation Current
Threshold
0.00 399.99 50.00 50.00 50.00 50.00 50.00 50.00 50.00 50.00 50.00 50.00 50.00 50.00 On/Off Y Y
P395 Flying Start Compensation Frequency
Reduce Speed
10 16384 50 50 50 50 50 50 50 50 50 50 50 50 On/Off Y Y
P396Deceleration Control Enable 0 1111111111111 On/OffYY
P397 DC Bus Lower Limit 0 32767 700 700 950 950 900 900 1000 950 950 1000 1000 1000 V On/Off Y Y
P398 DC Bus Upper Limit 0 32767 800 800 1050 1050 1000 1000 1050 1050 1050 1050 1050 1050 V On/Off Y Y
P399 Deceleration Time 1.0 3276.7 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 s On/Off Y Y Y
P401 Acceleration Time 1.0 3276.7 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 s On/Off Y Y Y
P402 Acceleration Ramp Transition Time 0.00 100.00 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 % On/Off Y
P403 Acceleration Time Unit 0.0 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 On/Off Y
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
To Next Page
