11.13.2.4 Defining the overlap tolerance at the field boundary
The overlap tolerance at the field boundary defines
how far the outer part-width sections can protrude
over the field boundary before they are switched off.
Overlap tolerance at the field boundary prevents the
outer part-width sections from being constantly
switched on and off when driving along and touching
a field boundary. This is because a degree of overlap
of 0 % is always set at the field boundary.
CMS-I-001467
Select "GPS switch" > > "Overlap tolerance
at field boundary".
Possible settings:
Value between 0 cm and 25 cm
CMS-I-002273
CMS-T-003440-A.1
11 | Using the GPS switch
Using part-width section control
MG5560-EN-II | E.1 | 21.04.2020
115
