Amazone AMATRON 3 User Manual

Possible settings:
Define the AUX-N assignment using the functions list,
see page 32
Define the AUX-N assignment using the input list, see
page 33
7.9.1.1
Defining the AUX-N assignment using the functions list
For the AUX-N assignment using the functions list, all
of the available functions are listed on the left side.
The buttons of an external input device can be
assigned to these functions.
1. If the functions are not listed on the left side:
Select .
2. Select a function from the list.
The list of available buttons will be opened.
3. Select a button from the list.
The selected button is assigned to the function.
CMS-T-002245-A.1
7 | AMATRON 3 configuration
Using AUX-N input devices
MG5560-EN-II | E.1 | 21.04.2020
32
