HDMI Input & Output Boards
100
Enova Digital Media Switchers - Hardware Reference Manual
HDMI Board EDID Resolutions Supported via Local DDC
Standard and established timings are given in the tables following along with detailed timing blocks.
NOTE: This section covers all of the default EDIDs for HDMI Input and Output Boards (not 4K HDMI Boards). In the System
Configuration interface, the EDIDs contained in this section's tables are displayed in a single dropdown menu (General
section, Preferred EDID menu) and VICs are differentiated by the presence of a "p" or "I" in the format. EDID information for
4K HDMI Boards is located on the following page.
IMPORTANT: The EDID can be re-programmed to support additional resolutions through the local DDC using the EDID
programming functionality in the System Configuration interface (see page 140).
Standard Timings (Default Shipping EDID)
NOTE: The default EDID can be overwritten to include a broad range of features, including HDMI mode, based on
installation requirements.
Established Timings
NOTE: Audio problems may result from passing Dolby or DTS or high PCM frequency rates to a destination device that
does not support them. Video problems may result from passing a video format that the destination device does not
support. In either of these cases, re-programming the EDID may help resolve the problem.
Resolution Refresh Rate Max.
1920x1080 60 Hz (Preferred timing identified in the EDID.
1920x1200 60 Hz
1680x1050 60 Hz
1600x1200 60 Hz
1600x900 60 Hz
1400x1050 60 Hz
1440x900 60 Hz
1360x765 60 Hz
1280x1024 60 Hz
1280x960 60 Hz
1280x800 60 Hz
1280x720 60 Hz
Resolution Refresh Rate Max.
1280x1024 75 Hz
1152x870 75 Hz
1024x768 60 Hz, 70 Hz, 75 Hz, 87 Hz
832x624 75 Hz
800x600 56 Hz, 60 Hz, 72 Hz, 75 Hz
720x400 70 Hz, 88 Hz
640x480 60 Hz, 67 Hz, 72 Hz, 75 Hz
