AMX Enova DGX 100 Series Hardware Reference Manual

4K60 HDMI Input & Output Boards
85
Enova Digital Media Switchers - Hardware Reference Manual
4K60 HDMI Board Default EDID Resolutions Supported through Local DDC
The following tables provide the default EDID for 4K60 HDMI Boards, which is the same as the default for 4K30 boards. If 4K
50Hz or 60Hz support is desired, selection of the 4K60 EDID is required (see page 86 for details).
NOTE: In the System Configuration interface, the EDIDs contained in these tables are displayed in a single dropdown
menu (General section, Preferred EDID menu), and progressive vs interface CTA VICs are differentiated by the presence
of a "p" or "I" in the format.
4K HDMI DTD (Detailed Timing Descriptor)
4K HDMI CTA Video Information Code (VIC) Formats
DGX-O-HDMI-4K60 (FG1061-552) - Specifications
CEC Support None
Output +5V DDC Pin 200mA max per output port
HDMI Output Board Video
Propagation Delay
5 us
Connectors 4 HDMI Type A Female Ports
HDMI Audio Synchronization
(Embedded Audio Mode)
Audio lags video by 1 ms
HDMI Audio Synchronization
(Switched Audio Mode)
Audio lags video by 33ms default – Adjustable down to 1 ms lag
* Compatible Enova DGX 100 Series Enclosures are those Enova DGX 800, 1600, 3200 or 6400 enclosures built on or after June 1, 2016
Resolution Refresh Rate and Aspect Ratio Video Standard
3840x2160p* 29.97/30 Hz 16:9 CTA (VIC 95)
1920x1080p 59.94/60 Hz 16:9 CTA (VIC 16)
1920x1080p 50 Hz 16:9 CTA (VIC 31)
1920x1200 50 Hz 16:10 CVR
1920x1200 60 Hz 16:10 CVR
3840 x 2160 29.97/30 Hz 16:9 95
3840 x 2160 25 Hz 16:9 94
3840 x 2160 23.98/24 Hz 16:9 93
4096 x 2160 23.98/24 Hz 256:135 98
* This is the preferred Format identified in the EDID.
SVD # Resolution Refresh Rate and Aspect Ratio VIC # CTA VIC HDMI VIC
001 3840x2160p 29.97/30 Hz 16:9 VIC = 95 1
002 3840x2160p 25 Hz 16:9 VIC = 94 2
003 3840x2160p 23.98/24 Hz 16:9 VIC = 93 3
004 4096x2160p 30 Hz 256:135 VIC = 100
005 4096x2160p 24 Hz 256:135 VIC = 98 4
006 4096x2160p 25 Hz 256:135 VIC = 99
007 3840x2160p 30 Hz 64:27 VIC = 105
008 3840x2160p 24 Hz 64:27 VIC = 103
009 3840x2160p 25 Hz 64:27 VIC = 104
010 1920x1080p 59.94/60 Hz 16:9 VIC = 16
011 1920x1080p 23.97/24 Hz 16:9 VIC = 32
012 1920x1080p 29.97/30 Hz 16:9 VIC = 34
013 1920x1080p 50 Hz 16:9 VIC = 31
014 1920x1080p 25 Hz 16:9 VIC = 33
015 1920x1080i 59.94/60 Hz 16:9 VIC = 5
016 1920x1080i 50 Hz 16:9 VIC = 20
017 1280x720p 59.94/60 Hz 16:9 VIC = 4
018 720x480p 59.94/60 Hz 16:9 VIC = 3
019 1280x720p 50 Hz 16:9 VIC = 19
020 720x480p 59.94/60 Hz 4:3 VIC = 2
021 720x576p 50 Hz 4:3 VIC = 17
022 720(1440)x480i 59.94/60 Hz 4:3 VIC = 6
023 720(1440)x480i 59.94/60 Hz 16:9 VIC = 7
