HDMI Input & Output Boards
96
Enova Digital Media Switchers - Hardware Reference Manual
InstaGate Pro and SmartScale
HDMI Boards are HDCP 1.4 compatible and feature InstaGate Pro Technology for low-latency switching of HDCP
protected content and support computer video up to 1920x1200 and HDTV up to 1080p. The HDMI Boards also
support embedded audio, both linear PCM (stereo audio) and non-linear PCM (Dolby Digital, DTS, Dolby TrueHD,
etc.).
NOTE:
InstaGate Pro Technology eliminates HDCP latency and interruptions on all displays in a system. (These conditions are
typically experienced when HDCP authenticates HDMI source and destination devices.) With InstaGate Pro Technology, when
a source requires HDCP encrypted content, the inputs and compliant downstream devices are automatically authenticated ?
it just works.
4K HDMI Boards are HDCP 1.4 compatible and feature InstaGate Pro Technology* for low-latency switching of
HDCP protected content and support progressive resolutions from 480p up to 4096x2160p@60Hz (Y/Cb/Cr 4:2:0).
4K HDMI Boards also support embedded audio, both linear PCM (stereo audio) and non-linear PCM (Dolby Digital,
DTS, Dolby TrueHD, etc.).
HDMI Boards meet HDCP Standards. For information on HDCP functionality for HDMI Boards, see "HDCP Support on
Enova DGX Switchers" on page 103.
HDMI Boards provide EDID emulation support with plug-and-play information provided by the Enova DGX
Switcher.
HDMI Output Boards feature SmartScale Technology which automatically responds to the preferred EDID
information and scales the video to the best resolution and video settings for that display without manual setup.
Enova DGX HDMI Input Board - Specifications
DGX HDMI Input Board - Specifications
GENERAL
Compatible AMX Products Supported enclosures are Enova DGX 800, 1600, 3200 or 6400 Digital Media Enclosure built after June 1,
2016
Regulatory Compliance See Enova DGX Digital Media Switcher Enclosure for regulatory compliance
HDMI w/HDCP DESCRIPTION
Compatible Formats HDMI 1.X, HDMI 2.0, HDCP 1.X, HDCP 2.2, DVI
Signal Type Support HDMI, DisplayPort++ (Input Only)
DVI-D (Single Link With HDMI Cable Adapter)
Video Data Rate (Max) When used with compatible Enova DGX 100 series enclosures*: 18 Gbps (Max)
Video Pixel Clock (Max) When used with compatible Enova DGX 100 series enclosures*: Up to 600 MHz
Progressive Resolution Support When used with compatible Enova DGX 100 series enclosures*: 480p up to 4096x2160 @ 60Hz, 4:4:4
Interlaced Resolution Support 480i, 576i, 1080i
NOTE: If input is interlaced, all scaled outputs will de-interlace video to a progressive resolution format. If
non-scaled output board or if scaler is in Bypass mode, interlaced input will pass through unaltered.
4K Resolution Support (Max) When used with compatible Enova DGX 100 series enclosures*:
• 3840x2160p @ 24/25/30/50/60 Hz, 4:4:4
• 4096x2160p @ 24/25/30/50/60 Hz, 4:4:4
• 3840x2160p @ 50/60 Hz, 4:2:0**
• 4096x2160p @ 50/60 Hz, 4:2:0**
** Supported by DX-RX-4K when in Bypass Scaling mode.
HDMI Cable Requirement Premium Certified High Speed Cable Category 2, Recommended. HDMI High Speed Cable Category 2,
Required
Input Equalization Adaptive up to 21ft (7m). Cable distance support dependent on cable quality and signal format
Input Re-clocking (CDR) Yes
Deep Color Support 24-bit, 30-bit***, 36-bit***
***30-bit and 36 bit are only supported in CTA-861 formats. When switched to an output board or RX with
Scaling support the Scaler must be in Bypass mode.
HDR Support Yes HDR10
Output signal follows input format
Note: Requires the use of HDR compatible output board such as 4K60 HDMI Output Board
Color Space Support sRGB, BT.601, BT.709, BT.2020
RGB 4:4:4 , YCbCr 4:4:4, 4:2:2, and 4:2:0
• Input signal support for YCbCr 4:4:4 and 4:2:2, output color-space is converted to RGB 4:4:4 on scaled
output
• Output signal follows input format on non-scaled output boards
• If 4:2:0 is switched to a 4K RX the RX scaler must be set to bypass
