DGX 1600
38
Enova Digital Media Switchers - Hardware Reference Manual
Specifications
DGX 1600 Specifications
Parameter Value
Approvals UL 60950-1, CSA 60950-1, IEC 60950-1, IEC 62368-1, CE EN 60950-1,
CE EN 55022 Class A, CE EN 55024, FCC CFR Title 47 Part 15 Subpart B Class A,
ICES-003 Class A, RoHS, WEEE
AC Power per Supply 100-240 +/-10% VAC single phase, 50/60 Hz
Power Capacity (max.) 977 Watts (110 VAC and 230 VAC)
Power Consumption (max.) 953 Watts, fully loaded DXLink Power enclosure with redundancy
Power Consumption (typical) 182 Watts, fully loaded 4K60 HDMI enclosure with redundancy
Thermal Dissipation Full Capacity (max.) 3334 BTU/hr.
Thermal Dissipation (max.) 3251 BTU/hr, fully loaded DXLink Power enclosure with redundancy
Thermal Dissipation (typical) 621 BTU/hr, fully loaded 4K60 HDMI enclosure with redundancy
Power Factor Correction (PFC) Supported, complies with EN60555-2 and EN61000-3-2
Operational Temperature 32° F to 104° F (0° C to 40° C)
Storage Temperature -22° F to 158° F (-30° C to 70° C)
Operational Humidity 5% to 85% RH (non-condensing)
Storage Humidity 0 to 90% RH (non-condensing)
MTBF 627,105 hrs
Dimensions • 15 in. (38.1 cm) depth; 16 in. (40.64 cm) depth with extractors
• 19 in. (48.26 cm) width including integral rack mounting ears
• 6.84 in. (17.37 cm) height (4 RU)
Weight Approximately 55 lb. (24.95 kg) per loaded enclosure
Shipping Weight Approximately 65 lb. (29.5 kg) per loaded enclosure
Per Channel Aggregate Data Rate (max.) 26 Gbps
Noise Level <52.5 dBA @ 1 m (typical @ 25° C)
Airflow Forced air (inlet on side; exhaust on side)
Compatible DXLinkâ„¢ Twisted Pair Transmitters and
Receivers
• DXLink Multi-Format Transmitter Modules
• DXLink Multi-Format Wallplate Transmitters
• DXLink Multi-Format Decor Style Wallplate Transmitter (US)
• DXLink HDMI Receiver Modules
Compatible DXLinkâ„¢ Twisted Pair 4K Transmitters
and Receivers
• DXLink 4K HDMI Decor Style Wallplate Transmitters (US)
• DXLink HDMI 4K Receiver Modules
Compatible DXLinkâ„¢ Fiber Transmitters and
Receivers
• DXLink Multi-Format MM Fiber TX, Duplex/Simplex
• DXLink Multi-Format SM Fiber TX, Duplex/Simplex
• DXLink HDMI MM Fiber RX, Duplex/Simplex
• DXLink HDMI SM Fiber RX, Duplex/Simplex
Compatible Solecis Digital Switchers • Solecis 4x1 HDMI Digital Switcher with DXLink Output
• Solecis 5x1 Multi-Format Digital Switcher with DXLink Output
• Solecis 8x1 HDMI Digital Switcher with DXLink Output
Compatible Solecis 4K Digital Switchers • Solecis 4x1 4K HDMI Digital Switcher with DXLink Output
• Solecis 5x1 4K Multi-Format Digital Switcher with DXLink Output
