Integrated Master - NetLinx Programming
206
Enova Digital Media Switchers - Hardware Reference Manual
Enova DGX 3200 Port Mapping
Input Port Mapping Output Port Mapping
Port # Description Address Port # Description Address
1 Audio/Video Input 1 5002:1:0 1 Audio/Video Output 1 5002:1:0
2 Audio/Video Input 2 5002:2:0 2 Audio/Video Output 2 5002:2:0
3 Audio/Video Input 3 5002:3:0 3 Audio/Video Output 3 5002:3:0
4 Audio/Video Input 4 5002:4:0 4 Audio/Video Output 4 5002:4:0
5 Audio/Video Input 5 5002:5:0 5 Audio/Video Output 5 5002:5:0
6 Audio/Video Input 6 5002:6:0 6 Audio/Video Output 6 5002:6:0
7 Audio/Video Input 7 5002:7:0 7 Audio/Video Output 7 5002:7:0
8 Audio/Video Input 8 5002:8:0 8 Audio/Video Output 8 5002:8:0
9 Audio/Video Input 9 5002:9:0 9 Audio/Video Output 9 5002:9:0
10 Audio/Video Input 10 5002:10:0 10 Audio/Video Output 10 5002:10:0
11 Audio/Video Input 11 5002:11:0 11 Audio/Video Output 11 5002:11:0
12 Audio/Video Input 12 5002:12:0 12 Audio/Video Output 12 5002:12:0
13 Audio/Video Input 13 5002:13:0 13 Audio/Video Output 13 5002:13:0
14 Audio/Video Input 14 5002:14:0 14 Audio/Video Output 14 5002:14:0
15 Audio/Video Input 15 5002:15:0 15 Audio/Video Output 15 5002:15:0
16 Audio/Video Input 16 5002:16:0 16 Audio/Video Output 16 5002:16:0
17 Audio/Video Input 17 5002:17:0 17 Audio/Video Output 17 5002:17:0
18 Audio/Video Input 18 5002:18:0 18 Audio/Video Output 18 5002:18:0
19 Audio/Video Input 19 5002:19:0 19 Audio/Video Output 19 5002:19:0
20 Audio/Video Input 20 5002:20:0 20 Audio/Video Output 20 5002:20:0
21 Audio/Video Input 21 5002:21:0 21 Audio/Video Output 21 5002:21:0
22 Audio/Video Input 22 5002:22:0 22 Audio/Video Output 22 5002:22:0
23 Audio/Video Input 23 5002:23:0 23 Audio/Video Output 23 5002:23:0
24 Audio/Video Input 24 5002:24:0 24 Audio/Video Output 24 5002:24:0
25 Audio/Video Input 25 5002:25:0 25 Audio/Video Output 25 5002:25:0
26 Audio/Video Input 26 5002:26:0 26 Audio/Video Output 26 5002:26:0
27 Audio/Video Input 27 5002:27:0 27 Audio/Video Output 27 5002:27:0
28 Audio/Video Input 28 5002:28:0 28 Audio/Video Output 28 5002:28:0
29 Audio/Video Input 29 5002:29:0 29 Audio/Video Output 29 5002:29:0
30 Audio/Video Input 30 5002:30:0 30 Audio/Video Output 30 5002:30:0
31 Audio/Video Input 31 5002:31:0 31 Audio/Video Output 31 5002:31:0
32 Audio/Video Input 32 5002:32:0 32 Audio/Video Output 32 5002:32:0
33 Audio Input 33 5002:33:0 33 Audio Output 33 5002:33:0
34 Audio Input 34 5002:34:0 34 Audio Output 34 5002:34:0
35 Audio Input 35 5002:35:0 35 Audio Output 35 5002:35:0
36 Audio Input 36 5002:36:0 36 Audio Output 36 5002:36:0
37 Audio Input 37 5002:37:0 37 Audio Output 37 5002:37:0
38 Audio Input 38 5002:38:0 38 Audio Output 38 5002:38:0
39 Audio Input 39 5002:39:0 39 Audio Output 39 5002:39:0
40 Audio Input 40 5002:40:0 40 Audio Output 40 5002:40:0
41 down-mix Input 41 5002:41:0
