AMX Enova DGX 100 Series Hardware Reference Manual

HDMI Input & Output Boards
99
Enova Digital Media Switchers - Hardware Reference Manual
Enova DGX HDMI Output Board - Specifications
DGX HDMI Output Board - Specifications
GENERAL
Compatible AMX Products Supported enclosures are Enova DGX 800, 1600, 3200 or 6400 Digital Media Enclosure built after June 1,
2016
Regulatory Compliance See Enova DGX Digital Media Switcher Enclosure for regulatory compliance
HDMI w/HDCP DESCRIPTION
Compatible Formats HDMI 1.X, HDMI 2.0, HDCP 1.X, HDCP 2.2, DVI
Signal Type Support HDMI, DisplayPort++
DVI-D (Single Link With HDMI Cable Adapter)
Video Data Rate (Max) When used with compatible Enova DGX 100 series enclosures*: 18 Gbps (Max)
Video Pixel Clock (Max) When used with compatible Enova DGX 100 series enclosures*: Up to 600 MHz
Progressive Resolution Support When used with compatible Enova DGX 100 series enclosures*
480p up to 4096x2160@ 60 Hz 4:4:4 including 3840x2160 @ 60 4:4:4
4K Resolution Support (Max) When used with compatible Enova DGX 100 series enclosures*:
• 3840x2160p @ 24/25/30/50/60 Hz, 4:4:4
• 4096x2160p @ 24/25/30/50/60 Hz, 4:4:4
• 3840x2160p @ 50/60 Hz, 4:2:0
• 4096x2160p @ 50/60 Hz, 4:2:0
HDMI Cable Requirement Premium Certified High Speed Cable Category 2, Recommended.
HDMI High Speed Cable Category 2, Required
Output Re-clocking Yes
Output Scaling None
Deep Color Support 24-bit, 30-bit**, 36-bit**
Output signal follows input format
**30-bit and 36-bit are only supported in CTA-861 formats.
HDR Support Yes HDR10
Output signal follows input format
Color Space Support • sRGB, BT601, BT.709, BT.220
• RGB 4:4:4; YCbCr 4:4:4 and 4:2:2 and 4:2:0
• Output signal follows input format
3D Format Support • Yes (HDMI Primary Formats)
• Frame Packing 1080p up to 24 Hz
• Frame Packing 720p up to 50/60 Hz
• Frame Packing 1080i up to 50/60 Hz
• Top-Bottom 1080p up to 24 Hz
• Top-Bottom 720p up to 50/60 Hz
• Side-by-Side Half 1080i up to 50/60 Hz
Audio Format Support Dolby Atmos, Dolby TrueHD, Dolby Digital, Dolby Digital, Plus, DTS-HD Master Audio, DTS, 2 CH through
8 CH L-PCM
Audio Resolution 16 bit to 24 bit
Audio Sample Rate 32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192kHz
Local Audio Support Yes, Insertion of 2 CH L-PCM selectable by channel
DDC/EDID Support Outputs can copy and save connected display EDID for use on Inputs as Custom EDIDs
HDCP Support • Yes, including HDCP 1.x and HDCP 2.x for full matrix HDCP support (includes any input to any or all
outputs)
• HDCP 2.2 support required by input/output board for passage of HDCP 2.2 premium content
• Key Management System
• AMX HDCP InstaGate Pro™ Technology
• Key support up to max 31 devices downstream on one output
CEC Support None
Output +5V DDC Pin 200mA max per output port
Connectors 4 HDMI Type A Female Ports
HDMI Output Board
Propagation Delay
5 us
HDMI Audio Synchronization
(Embedded Audio Mode)
Audio lags video by 1 ms
HDMI Audio Synchronization
(Switched Audio Mode)
Audio lags video by 33ms default – Adjustable down to 1 ms lag
Audio Switching Board Support Supports break-away audio switching of 2 CH L-PCM for all channels
* Compatible Enova DGX 100 Series Enclosures are those Enova DGX 800, 1600, 3200 or 6400 enclosures built on or after June 1, 2016
