Dante Audio Switching Boards Specifications
The following specifications apply to Dante Audio Switching Board sets FG1061-832 and FG1061-864:
Dante Audio Switching Boards Specifications
Compatible AMX Systems • Enova DGX 100 Series Digital Media Switchers
• Enova DGX 800/1600/3200 (DGX3200-ASB-DAN)
• Enova DGX 6400 (DGX6400-ASB-DAN)
Compatible Enova DGX I/O
Boards
• DGX-I-HDMI, Enova DGX HDMI Input Board (FG1058-540)
• DGX-I-HDMI-4K, Enova DGX 4K HDMI Input Board (FG1061-540)
• DGX-O-HDMI, Enova DGX HDMI Output Board (FG1058-550)
• DGX-I-DVI, Enova DGX DVI Input Board (FG1058-600)
• DGX-O-DVI, Enova DGX DVI Output Board (FG1058-610)
• DGX-I-DXL, Enova DGX DXLink Twisted Pair Input Board (FG1058-570)
• DGX-O-DXL, Enova DGX DXLink Twisted Pair Output Board (FG1058-580)
• DGX-I-DXL-4K, Enova DGX DXLink Twisted Pair 4K Input Board (FG1061-570)
• DGX-O-DXL-4K, Enova DGX DXLink Twisted Pair 4K Output Board (FG1061-580)
• DGX-I-DXF-MMD Enova DGX DXLink Multimode Fiber Input Board, Duplex (FG1058-622)
• DGX-O-DXF-MMD, Enova DGX DXLink Multimode Fiber Output Board, Duplex (FG1058-632)
• DGX-I-DXF-MMS, Enova DGX DXLink Multimode Fiber Input Board, Simplex (FG1058-623)
• DGX-O-DXF-MMS, Enova DGX DXLink Multimode Fiber Output Board, Simplex (FG1058-633)
• DGX-I-DXF-SMD, Enova DGX DXLink Single Mode Fiber Input Board, Duplex (FG1058-620)
• DGX-O-DXF-SMD, Enova DGX DXLink Single Mode Fiber Output Board, Duplex (FG1058-630)
• DGX-I-DXF-SMS, Enova DGX DXLink Single Mode Fiber Input Board, Simplex (FG1058-621)
• DGX-O-DXF-SMS, Enova DGX DXLink Single Mode Fiber Output Board, Simplex (FG1058-631)
Audio Switching • 16x16 for Enova DGX 800, 24x24 for Enova DGX 1600,
• 40x40 for Enova DGX 3200, 80x80 for Enova DGX 6400
• Each embedded or auxiliary Dante audio output has independent volume, EQ, and sync delay.
Audio Inputs Auxiliary Dante Audio Input Connections:
(2) Dante Interface RJ-45 connectors on the input board; support for redundant network or daisy chain
(Dante Switched Mode) network configuration; Input board supports 8 channels of stereo audio from
the Dante network into the DGX
• 8, 16 or 32 embedded digital audio inputs from video input positions (embedded audio must originate
as 2 channel PCM) - Applies to embedded audio inputs on Enova DGX Input Boards for positions 1-8
(DGX 800) / 1-16 (DGX 1600) / 1-32 (DGX 3200)
• 8 Auxiliary Dante stereo audio inputs on the Input Board of the Audio Switching Board Kit - Dante
Audio inputs 9-16 (DGX 800), 17-24 (DGX 1600), 33-40 (DGX-3200)
Audio Outputs Auxiliary Dante Audio Output Connections:
(2) Dante Interface RJ-45 connectors on the output board; support for redundant network or daisy chain
network configuration; Output board provides 8 channels of stereo audio from the DGX into the Dante
network
• 8, 16 or 32 embedded digital audio to video outputs - Applies to embedded audio outputs on Enova
DGX Output Boards for positions 1-8 (DGX 800) / 1-16 (DGX 1600) / 1-32 (DGX 3200)
• 8 Auxiliary Dante audio outputs on the Output Board of the Audio Switching Board Kit - Dante Audio
outputs 9-16 (DGX 800), 17-24 (DGX 1600), 33-40 (DGX-3200)
Audio Adjustments per Input
(embedded video and
auxiliary inputs)
Audio Input Compression:
• Independent Compression per input
• Low, Med, High, and Custom Presets
• Attack: 1 to 2000 ms
• Release: 10 to 5000 ms
• Compression Ratio: 1 to 20
• Threshold: -60 to 0 dB
Audio Input Gain Compensation: -24 dB to +24 dB, 1 dB steps
Audio Mixing: Mono to Stereo conversion per input
Audio DSP Adjustments Per
Output (embedded video and
auxiliary outputs)
Audio Output DSP:
• Independent EQ, Volume and Balance control per output
• 10-band parametric EQ with variable center frequency, filter type and Q per band
Center Frequency: 20 Hz to 20 kHz
EQ Gain: -12 to +12 dB
Q: 0.1 to 20
Filter Types: Bell, Base Shelving, Treble Shelving, Low Pass, High Pass, Band Pass, Band Stop
• Audio Output Volume adjustments with minimum and maximum limiter settings per output
• Audio Output Sync Delay: 0 to 200 ms (Default 32ms)
• Balance Control: 20 steps each, left and right
Audio Mixing: Stereo to Mono conversion per output
Test Tone Generator: Single selection of test tone type available on all outputs simultaneously.
Individually enabled/disabled per output - 60 Hz, 250 Hz, 400 Hz, 1 kHz, 3,Hz, 5 kHz, 10 kHz, Pink Noise,
White Noise.
