DXLink Twisted Pair Input and Output Boards
115
Enova Digital Media Switchers - Hardware Reference Manual
Established Timings
NOTE: Audio problems may result from passing Dolby or DTS or high PCM frequency rates to a destination device that
does not support them. Video problems may result from passing a video format that the destination device does not
support. In either of these cases, re-programming the EDID may help resolve the problem.
CTA Video Information Code (VIC) Formats
Audio Data Block
IMPORTANT: For information on troubleshooting audio, including a table on "Audio Format Support on Enova DGX Boards,"
see page 101.
Resolution Refresh Rate Max.
1280x1024 75 Hz
1152x870 75 Hz
1024x768 60 Hz, 70 Hz, 75 Hz, 87 Hz
832x624 75 Hz
800x600 56 Hz, 60 Hz, 72 Hz, 75 Hz
720x400 70 Hz, 88 Hz
640x480 60 Hz, 67 Hz, 72 Hz, 75 Hz
VIC # Resolution Refresh Rate and Aspect Ratio
VIC = 1 640x480p 59.94/60 Hz 4:3
VIC = 2 720x480p 59.94/60 Hz 4:3
VIC = 3 720x480p 59.94/60 Hz 16:9
VIC = 4 1280x720p 59.94/60 Hz 16:9
VIC = 5 1920x1080i 59.94/60 Hz 16:9
VIC = 6 720(1440)x480i 59.94/60 Hz 4:3
VIC = 7 720(1440)x480i 59.94/60 Hz 16:9
VIC = 14 1440x480p 59.94/60 Hz 4:3
VIC = 15 1440x480p 59.94/60 Hz 16:9
VIC = 16 Native 1920x1080p 59.94/60 Hz 16:9
VIC = 17 720x576p 50 Hz 4:3
VIC = 18 720x576p 50 Hz 16:9
VIC = 19 1280x720p 50 Hz 16:9
VIC = 20 1920x1080i 50 Hz 16:9
VIC = 21 720(1440)x576i 50 Hz 4:3
VIC = 22 720(1440)x576i 50 Hz 16:9
VIC = 29 1440x576p 50 Hz 4:3
VIC = 30 1440x576p 50 Hz 16:9
VIC = 31 1920x1080p 50 Hz 16:9
VIC = 32 1920x1080p 23.97/24 Hz 16:9
VIC = 33 1920x1080p 25 Hz 16:9
VIC = 34 1920x1080p 29.97/30 Hz 16:9
VIC = 39 1920x1080i 50 Hz 16:9
VIC = 41 1280x720p 100 Hz 16:9
VIC = 42 720x576p 100 Hz 4:3
VIC = 43 720x576p 100 Hz 16:9
VIC = 44 720(1440)x576i 100 Hz 4:3
VIC = 45 720(1440)x576i 100 Hz 16:9
VIC = 47 1280x720p 119.88/120 Hz 16:9
VIC = 48 720x480p 119.88/120 Hz 4:3
VIC = 49 720x480p 119.88/120 Hz 16:9
Channels Sampling Frequency
Basic Audio: 2 channel L-PCM 32, 44.1, 48 kHz Sampling frequency at 16, 20, or 24 bits per sample
