4K60 HDMI Input & Output Boards
94
Enova Digital Media Switchers - Hardware Reference Manual
Determining the DxLink Transmitter Source Audio Port
Audio Format Support on Enova DGX Boards
The following table indicates which audio formats are supported by specific Enova DGX boards.
NOTE: In order to pass audio over the DVI Input boards their EDID need to be changed to an HDMI EDID which allow
Audio formats to be seen as supported by the source.
IMPORTANT: Signals routed through HDMI, 4K HDMI, 4K60 HDMI, DVI, DXLink Twisted Pair, and DXLink Fiber Boards normally
produce a quality image. If the installation has special scaling, EDID, or HDCP requirements, see page 199.
Active Video ?AUDIN_FORMAT_AUTO Source Audio Port
HDMI ENABLED HDMI
VGA/Analog ENABLED Whichever port is set in ?AUDIN_FORMAT
HDMI DISABLED Whichever port is set in ?AUDIN_FORMAT
VGA/Analog DISABLED Whichever port is set in ?AUDIN_FORMAT
Audio Format Support on Enova DGX Boards
Audio Format
Board Types
4k60 HDMI
Input and Output boards
HDMI / 4K HDMI
Input Boards
HDMI Output Boards
DVI Input Boards
DVI Output Boards
DXLink Twisted Pair
Input and Output Boards
DXLink Fiber
Input and Output Boards
Dante Audio
Switching Boards
Audio Switching Boards
(ASB and ASB-DAN)
Audio Insert/Extract
Expansion Boards
( input and output)
2 Channel L-PCM ••••••••• •
6 Channel L-PCM •••••••
8 Channel L-PCM •••••••
Dolby Digital • • • • • •* •*
DTS ••••••* •*
Dolby TrueHD • • • • •
DTS-HD Master • • • • •
Dolby Atmos •
* Dolby Digital and DTS support up to 48 kHz, 5.1 channels.
