DXLink Fiber Input & Output Boards
138
Enova Digital Media Switchers - Hardware Reference Manual
EDID Resolutions Supported through Local DDC
This section covers all of the default EDIDs. In the System Configuration interface, the EDIDs contained in this section's
tables are displayed in a single dropdown menu (General section, Preferred EDID menu) and VICs are differentiated by
the presence of a "p" or "I" in the format. Standard and established timings are given in the tables following, along with
detailed timing blocks.
IMPORTANT: The EDID can be configured to support additional resolutions through the local DDC using the EDID options in
the System Configuration interface (see page 140).
NOTE: The Consumer Technology Association (CTA) was formerly known as the Consumer Electronics Association (CEA):
the CEA 861 video standard has been renamed to CTA 861.
Standard Timing Identification (Default Shipping EDID)
The default EDID can be overwritten to include a broad range of features based on installation requirements.
Established Timing
CTA Video Information Code (VIC) Formats
Resolution Refresh Rate Max.
1920x1080* 60 Hz
1920x1200 60 Hz
1680x1050 60 Hz
1600x1200 60 Hz
1600x900 60 Hz
1400x1050 60 Hz
1440x900 60 Hz
1360x765 60 Hz
1280x1024 60 Hz
1280x900 60 Hz
1280x800 60 Hz
1280x720 60 Hz
* Preferred timing (identified in the EDID)
Resolution Refresh Rate
1280x1024 75 Hz
1152x870 75 Hz
1024x768 60 Hz, 70 Hz, 75 Hz, 87 Hz
832x624 75 Hz
800x600 56 HZ, 60 Hz, 72 Hz, 75 Hz
720x400 70 Hz, 88 Hz
640x480 60 Hz, 67 Hz, 72 Hz, 75 Hz
VIC # Resolution Refresh Rate and Aspect Ratio
VIC = 1 640x480p 59.94/60 Hz 4:3
VIC = 2 720x480p 59.94/60 Hz 4:3
VIC = 3 720x480p 59.94/60 Hz 16:9
VIC = 4 1280x720p 59.94/60 Hz 16:9
VIC = 5 1920x1080i 59.94/60 Hz 16:9
VIC = 6 720(1440)x480i 59.94/60 Hz 4:3
VIC = 7 720(1440)x480i 59.94/60 Hz 16:9
VIC = 14 1440x480p 59.94/60 Hz 4:3
VIC = 15 1440x480p 59.94/60 Hz 16:9
VIC = 16 Native 1920x1080p 59.94/60 Hz 16:9
VIC = 17 720x576p 50 Hz 4:3
VIC = 18 720x576p 50 Hz 16:9
VIC = 19 1280x720p 50 Hz 16:9
VIC = 20 1920x1080i 50 Hz 16:9
VIC = 21 720(1440)x576i 50 Hz 4:3
VIC = 22 720(1440)x576i 50 Hz 16:9
VIC = 29 1440x576p 50 Hz 4:3
VIC = 30 1440x576p 50 Hz 16:9
VIC = 31 1920x1080p 50 Hz 16:9
VIC = 32 1920x1080p 23.97/24 Hz 16:9
VIC = 33 1920x1080p 25 Hz 16:9
VIC = 34 1920x1080p 29.97/30 Hz 16:9
