DVI Input & Output Boards
109
Enova Digital Media Switchers - Hardware Reference Manual
CTA Video Information Code (VIC) Formats
NOTE: The Consumer Technology Association (CTA) was formerly known as the Consumer Electronics Association (CEA):
the CEA 861 video standard has been renamed to CTA 861.
Audio Data Block
IMPORTANT: For information on troubleshooting audio, including a table on "Audio Format Support on Enova DGX Boards,"
see page 111.
Connecting DVI Inputs and Outputs
Fasten the DVI-I (or DVI-D) connectors on the cable ends onto the DVI-I receptacles on the boards.
IMPORTANT: Screw down the DVI connector retention screws to secure the plug and ensure a good connection.
VIC # Resolution Refresh Rate and Aspect Ratio
VIC = 1 640x480p 59.94/60 Hz 4:3
VIC = 2 720x480p 59.94/60 Hz 4:3
VIC = 3 720x480p 59.94/60 Hz 16:9
VIC = 4 1280x720p 59.94/60 Hz 16:9
VIC = 5 1920x1080i 59.94/60 Hz 16:9
VIC = 6 720(1440)x480i 59.94/60 Hz 4:3
VIC = 7 720(1440)x480i 59.94/60 Hz 16:9
VIC = 14 1440x480p 59.94/60 Hz 4:3
VIC = 15 1440x480p 59.94/60 Hz 16:9
VIC = 16 Native 1920x1080p 59.94/60 Hz 16:9
VIC = 17 720x576p 50 Hz 4:3
VIC = 18 720x576p 50 Hz 16:9
VIC = 19 1280x720p 50 Hz 16:9
VIC = 20 1920x1080i 50 Hz 16:9
VIC = 21 720(1440)x576i 50 Hz 4:3
VIC = 22 720(1440)x576i 50 Hz 16:9
VIC = 29 1440x576p 50 Hz 4:3
VIC = 30 1440x576p 50 Hz 16:9
VIC = 31 1920x1080p 50 Hz 16:9
VIC = 32 1920x1080p 23.97/24 Hz 16:9
VIC = 33 1920x1080p 25 Hz 16:9
VIC = 34 1920x1080p 29.97/30 Hz 16:9
VIC = 39 1920x1080i 50 Hz 16:9
VIC = 41 1280x720p 100 Hz 16:9
VIC = 42 720x576p 100 Hz 4:3
VIC = 43 720x576p 100 Hz 16:9
VIC = 44 720(1440)x576i 100 Hz 4:3
VIC = 45 720(1440)x576i 100 Hz 16:9
VIC = 47 1280x720p 119.88/120 Hz 16:9
VIC = 48 720x480p 119.88/120 Hz 4:3
VIC = 49 720x480p 119.88/120 Hz 16:9
Channels Sampling Frequency
Basic Audio: 2 channel L-PCM 32, 44.1, 48 kHz Sampling frequency at 16, 20, or 24 bits per sample
