AMX Enova DGX 100 Series Hardware Reference Manual

Integrated Master - NetLinx Programming
228
Enova Digital Media Switchers - Hardware Reference Manual
Audio Output SEND_COMMANDs (Cont.)
Command Description
AUDOUT_EQ_ENABLE Enables or disables audio EQ on all ports.
Syntax:
SEND_COMMAND <DEV>, "'AUDOUT_EQ_ENABLE-<setting>'"
Variable:
• setting = desired EQ state, either ON or OFF
Example:
SEND_COMMAND dxDev, "'AUDOUT_EQ_ENABLE-OFF'"
?AUDOUT_EQ_FT Requests the filter type on the specified equalizer band on the audio output port addressed by the
D:P:S.
Syntax:
SEND_COMMAND <DEV>, "'?AUDOUT_EQ_FT-<band>'"
Example:
SEND_COMMAND AUDIO_OUTPUT_1, "'?AUDOUT_EQ_FT-1'"
Returns a COMMAND string of the form:
AUDOUT_EQ_FT-<band>,<filter>
Note: See the AUDOUT_EQ_FT command for the band range and filter types.
AUDOUT_EQ_FT Sets the filter type on the specified equalizer band on the audio output port addressed by the D:P:S
to <filter type>.
Syntax:
SEND_COMMAND <DEV>, "'AUDOUT_EQ_FT-<band>=<filter type>'"
Variables:
• band = 1 to 10 if on the audio output port.
• filter type = Bell, Band Pass, Band Stop, High Pass, Low Pass, Treble Shelf, Bass Shelf
Example:
SEND_COMMAND AUDIO_OUTPUT_1, "'AUDOUT_EQ_FT-1=Low Pass'"
Sets the filter type on band #1 of audio port 1 equalizer to Low Pass.
?AUDOUT_EQ_GAIN Requests the gain on the specified equalizer band on the audio output port addressed by the D:P:S.
Syntax:
SEND_COMMAND <DEV>, "'?AUDOUT_EQ_GAIN-<band>'"
Example:
SEND_COMMAND AUDIO_OUTPUT_1, "'?AUDOUT_EQ_GAIN-1'"
Returns a COMMAND string of the form:
AUDOUT_EQ_GAIN-<band>,<value>
Note: See the AUDOUT_EQ_GAIN command for the band and value ranges.
AUDOUT_EQ_GAIN Sets the gain on the specified equalizer band on the audio output port addressed by the D:P:S to
<value>.
Syntax:
SEND_COMMAND <DEV>, "'AUDOUT_EQ_GAIN-<band>,<value>'"
Variables:
• band = 1 to 10
• value = -12 to 12 (in dB)
Example:
SEND_COMMAND AUDIO_OUTPUT_1, "'AUDOUT_EQ_GAIN-1,8'"
Sets the gain on band #1 of audio port 1 equalizer to 8.
SEND_COMMAND AUDIO_OUTPUT_2, "'AUDOUT_EQ_GAIN-5,-10'"
Sets the gain on band #5 of audio port 2 equalizer to -10.
?AUDOUT_EQ_MODE Requests the current mode of the equalizer for the audio port addressed by the D:P:S.
Syntax:
SEND_COMMAND <DEV>, "?'AUDOUT_EQ_MODE'"
Example:
SEND_COMMAND AUDIO_OUTPUT_1, "'?AUDOUT_EQ_MODE'"
Returns a COMMAND string of the form:
AUDOUT_EQ_MODE-<mode>
Note: See the AUDOUT_EQ_MODE command for the list of mode settings.
AUDOUT_EQ_MODE Sets the mode for the equalizer for the audio port addressed by the D:P:S.
Syntax:
SEND_COMMAND <DEV>, "'AUDOUT_EQ_MODE-<mode>'"
Variables
• mode = off, voice, music, movie
Example:
SEND_COMMAND AUDIO_OUTPUT_1, "'AUDOUT_EQ_MODE-movie'"
Sets the equalizer to favor the sounds of a movie for the audio output port.
