AMX Enova DGX 100 Series Hardware Reference Manual

Enova DGX 100 Series - Overview
25
Enova Digital Media Switchers - Hardware Reference Manual
Enova DGX 100 Series - Overview
Applicability Notice
The information in this manual applies to the following Enova DGX 100 Series Digital Media Switcher enclosures, plus input,
output, and expansion boards, which can be ordered to create custom systems. All of the boards listed in this section are
compatible with the Enova DGX enclosures listed below:
All Enova DGX Switchers ship with a standard front control panel. See the Control Panel section on page 67 for details.
DGX Digital Media Switchers & Standard Video Input and Output Boards
Enova DGX 100 Series Switchers currently support four standard Enova DGX input and output board types: HDMI, DVI,
DXLink Twisted Pair, and DXLink Fiber Boards. Each board fills one of the standard I/O board slots and has four connectors.
Within a system, a source device connected to any of the input boards can be routed to any destination device
connected to any of the output boards (check the board chapters for important signal information when routing
between board types).
If a system has empty input or output board slots (which are numbered for additional inputs and outputs), the slots can be
used to expand the system. For information on adding or replacing boards, see "Appendix A – Adding or Replacing
Boards" on page 239.
NOTE: Two types of audio expansion boards are also available (see the Enova DGX Expansion Boards section on
page 27).
Enova DGX HDMI 4K60 Boards
Enova DGX HDMI Boards
Enova DGX DVI Boards
Enova DGX DXLink Twisted Pair Boards
NOTE: Enova DXLink Twisted Pair Boards must be used in conjunction with DXLink Twisted Pair Transmitters and Receivers or
other AMX DXLink signal management solutions. For model numbers of compatible Transmitters and Receivers, see
page 112. For system setup information, see page 116.
IMPORTANT: Before connecting a Solecis Digital Switcher to a DXLink Twisted Pair Input Board in an Enova DGX 100 Series
Digital Media Switcher, both the Solecis unit and all DXLink Twisted Pair boards must be upgraded with the latest available
firmware versions. Solecis units must
be upgraded before connecting a unit to an upgraded input board.
Enova DGX 100 Series Digital Media Switchers - Enclosures
Model Part # Rack Units Configuration Page #
DGX800-ENC FG1061-08 4RU 8x8 Video and up to 16x16 Audio with Audio Switching Boards page 35
DGX1600-ENC FG1061-16 4RU 16x16 Video and up to 24x24 Audio with Audio Switching Boards page 37
DGX3200-ENC FG1061-32 6RU 32x32 Video and up to 40x40 Audio with Audio Switching Boards page 39
DGX6400-ENC FG1061-64 13RU 64x64 Video and up to 80x80 Audio with Audio Switching Boards page 41
Type Part # Model
4K60 HDMI Input FG1061-542 DGX-I-HDMI-4K60
4K60 HDMI Output FG1061-552 DGX-O-HDMI-4K60
Type Part # Model
HDMI Input FG1058-540 DGX-I-HDMI
4K HDMI Input FG1061-540 DGX-I-HDMI-4K
HDMI Output FG1058-550 DGX-O-HDMI
Type Part # Model
DVI Input FG1058-600 DGX-I-DVI
DVI Output FG1058-610 DGX-O-DVI
Type Part # Model
DXLink Twisted Pair Input FG1058-570 DGX-I-DXL
DXLink Twisted Pair Output FG1058-580 DGX-O-DXL
