AMX Enova DGX 100 Series Hardware Reference Manual

Integrated Master - NetLinx Programming
232
Enova Digital Media Switchers - Hardware Reference Manual
DXLink Endpoint SEND_COMMANDs
IMPORTANT: The commands in this section affect endpoints, but are addressed to the input or output port connected to
the associated endpoint.
NetLinx NX Master Telnet Commands
The table below contains Telnet commands which apply to the integrated NetLinx NX Master.
NOTE:
For further information about using Telnet commands and a complete list of commands available for NetLinx NX Central
Controllers, see the NX-Series Controllers WebConsole & Programming Guide at www.amx.com
.
DXLink Endpoint SEND_COMMANDs
Command Description
?ENDPOINT_TX_ICSLAN_PORT Requests the IP configuration of the ICSLAN port on the DXLink TX.
Note: Does not apply to DXLink Wallplates.
Syntax:
SEND_COMMAND <DEV>, "'?ENDPOINT_TX_ICSLAN_PORT'"
Example:
SEND_COMMAND 5002:13:1, "'?ENDPOINT_TX_ICSLAN_PORT'"
Returns a COMMAND string of the form:
ENDPOINT_TX_ICSLAN_PORT-<PRIVATE|PUBLIC>
ENDPOINT_TX_ICSLAN_PORT Changes the IP configuration of the ICSLAN port on the DXLink TX.
Note: Does not apply to DXLink Wallplates.
Syntax:
SEND_COMMAND <DEV>, "'ENDPOINT_TX_ICSLAN_PORT-<PRIVATE|PUBLIC>'"
Example:
SEND_COMMAND 5002:13:1, "'ENDPOINT_TX_ICSLAN_PORT-PRIVATE'"
Note: Default setting for DXLink endpoints is PUBLIC.
?ENDPOINT_RX_ICSLAN_PORT Requests the IP configuration of the ICSLAN port on the DXLink RX.
Syntax:
SEND_COMMAND <DEV>, "'?ENDPOINT_RX_ICSLAN_PORT'"
Example:
SEND_COMMAND 5002:14:1, "'?ENDPOINT_RX_ICSLAN_PORT'"
Returns a COMMAND string of the form:
ENDPOINT_RX_ICSLAN_PORT-<PRIVATE|PUBLIC>
ENDPOINT_RX_ICSLAN_PORT Changes the IP configuration of the ICSLAN port on the DXLink RX.
Syntax:
SEND_COMMAND <DEV>, "'ENDPOINT_RX_ICSLAN_PORT-<PRIVATE|PUBLIC>'"
Example:
SEND_COMMAND 5002:14:1, "'ENDPOINT_RX_ICSLAN_PORT-PRIVATE'"
Note: Default setting for DXLink endpoints is PUBLIC.
NetLinx NX Telnet Commands for the Integrated NetLinx NX Master
Command Description
AUTO LOCATE
(ENABLE|DISABLE|STATUS)
Enables/disables/queries the auto locate feature on the integrated Master. Auto locate adds additional
broadcast information for use by AMX Touch Panel devices configured in Auto connect mode.
Syntax:
Auto Locate [enable|disable|status]
DOT1X
(ENABLE|DISABLE|STATUS)
Enables/disables 802.1x security or displays its current settings. The default settings is disable.
Syntax:
DOT1X[status|enable|disable]
MANAGE FIRMWARE Telnet interface to load previous and factory firmware versions for both the integrated Master (device 0)
and controller (device 5001).
Example:
>manage firmware
Devices
-------
0 - Master
5001
Select device or press return to cancel:0
Current Version: 1.2.259
Previous Version: 1.2.258
Factory Version: 1.2.250
To install a firmware version:
Enter P (Previous), F (Factory) or press return to cancel:
PROGRAM
(ENABLE|DISABLE|STATUS)
Enable/disable the NetLinx program or display the status of the current program execution setting.
The default setting is enable.
Note: For information on using this command, see page 79.
The setting (enable or disable) persists through power down and through firmware updates, etc., until a
new command is sent. If the software setting is disabled, then the NetLinx program is disabled.
Syntax:
PROGRAM [status|enable|disable]
