AMX Enova DGX 100 Series Hardware Reference Manual

4K60 HDMI Input & Output Boards
86
Enova Digital Media Switchers - Hardware Reference Manual
NOTE: The Consumer Technology Association (CTA) was formerly known as the Consumer Electronics Association (CEA):
the CEA 861 video standard has been renamed to CTA 861.
Audio Data Block
NOTE: For information on troubleshooting audio, including a table on "Audio Format Support on Enova DGX Boards," see
page 94.
4K60 HDMI Board EDID Resolutions - 50 Hz and 60 Hz Modes
The default EDID on the 4K60 HDMI Input board is the same as the 4K EDID on the 4K30 HDMI input boards. To enable
support of 4K 50Hz or 60Hz the default EDID must be changed to select the 4K60 EDID. This can be changed either using
the System Configuration Interface or the ICSP command VIDIN_EDID-4K60 (see the Standard Input/Output Boards:
SEND_COMMANDs section on page 213).
NOTE: In the System Configuration interface, the EDIDs contained in these tables are displayed in a single dropdown
menu (General section, Preferred EDID menu), and progressive vs interface CTA VICs are differentiated by the presence
of a "p" or "I" in the format.
Detailed Timings
HDMI VICs
Short Video Descriptors
024 720x576p 50 Hz 16:9 VIC = 18
025 720(1440)x576i 50 Hz 4:3 VIC = 21
026 720(1440)x576i 50 Hz 16:9 VIC = 22
027 1920x1080i 50 Hz 16:9 VIC = 39
028 2560x1080p 60 Hz 64:27 VIC = 90
029 2560x1080p 50 Hz 64:27 VIC = 89
030 640x480p 59.94/60 Hz 4:3 VIC = 1
Channels Sampling Frequency
Basic Audio: 2 channel L-PCM 32, 44.1, 48 kHz Sampling frequency at 16, 20, or 24 bits per sample
# Resolution Refresh Rate and Aspect Ratio CTA VIC
1 3840 x 2160* 59.94/60 Hz 16:9 97
2 1920 x 1080 59.94/60 Hz 16:9 16
3 1920 x 1200 50 Hz 16:10
4 1920 x 1200 60 Hz 16:10
* This is the preferred Format identified in the EDID.
# Resolution Refresh Rate and Aspect Ratio CTA VIC HDMI VIC
1 3840 x 2160 29.97/30 Hz 16:9 95 1
2 3840 x 2160 25 Hz 16:9 94 2
3 3840 x 2160 23.98/24 Hz 16:9 93 3
4 4096 x 2160 23.98/24 Hz 256:135 98 4
# Resolution Refresh Rate and Aspect Ratio CTA VIC
1 3840 x 2160p 59.94/60 Hz 16:9 97
2 3840 x 2160p 50 Hz 16:9 96
3 4096 x 2160p 59.94/60 Hz 256:135 102
4 4096 x 2160p 50 Hz 256:135 101
5 3840 x 2160p 29.97/30 Hz 16:9 95
6 3840 x 2160p 25 Hz 16:9 94
7 3840 x 2160p 23.98/24 Hz 16:9 93
8 4096 x 2160p 29.97/30 Hz 256:135 100
9 4096 x 2160p 23.98/24 Hz 256:135 98
10 4096 x 2160p 25 Hz 256:135 99
11 1920 x 1080p 59.94/60 Hz 16:9 16
12 1920 x 1080p 23.98/24 Hz 16:9 32
13 1920 x 1080p 29.97/30 Hz 16:9 34
14 1920 x 1080p 50 Hz 16:9 31
15 1920 x 1080p 25 Hz 16:9 33
16 1920 x 1080i 59.94/60 Hz 16:9 5
17 1920 x 1080i 50 Hz 16:9 20
18 1280 x 720p 59.94/60 Hz 16:9 4
19 720 x 480p 59.94/60 Hz 16:9 3
20 1280 x 720 50 Hz 16:9 19
21 720 x 480i 59.94/60 Hz 16:9 7
22 720 x 576 50 Hz 16:9 18
23 720 x 576i 50 Hz 16:9 22
SVD # Resolution Refresh Rate and Aspect Ratio VIC # CTA VIC HDMI VIC
